Sony PMW-F5 User Manual

Table of Contents
2
Overview
Features ...................................................................................... 6
System Configuration ............................................................... 9
Location and Function of Parts ............................................. 11
On-Screen Indications ............................................................ 17
Sub Display Screen ...................................................... 17
Viewfinder Screen ........................................................ 20
Preparations
Power Supply ........................................................................... 23
Using a Battery Pack .................................................... 23
Using AC Power (DC IN Power) ................................. 24
Setting the Clock ..................................................................... 24
Attaching Optional Devices .................................................... 25
Attaching a Lens .......................................................... 25
Attaching a Viewfinder ................................................ 26
Setting the Basic Action .......................................................... 27
System Frequency ........................................................ 27
Shooting Mode ............................................................. 27
Main Recorded Signal .................................................. 27
Color Space .................................................................. 28
Imager Scan Mode ....................................................... 28
Recording Format ......................................................... 28
Using SxS Memory Cards ...................................................... 29
About SxS Memory Cards ........................................... 29
Inserting an SxS Memory Card .................................... 30
Removing an SxS memory card ................................... 30
Switching Between SxS Memory Cards ...................... 30
Formatting an SxS Memory Card ................................ 30
Checking the Remaining Time Available for
Recording ............................................................... 31
Restoring an SxS Memory Card .................................. 31
Using an SD Card ................................................................... 32
Usable SD Cards .......................................................... 32
Inserting an SD Card .................................................... 32
Removing an SD memory card .................................... 32
Formatting an SD Memory Card .................................. 32
Table of Contents

Sony PMW-F5 Specifications

General

Sensor type	CMOS
Total megapixels	11.6 MP
Effective megapixels (movie)	8.9 MP
Optical zoom	- x
Image stabilizer	No
Interchangeable lens	Yes
Camcorder media type	Memory card
Compatible memory cards	SD
Internal storage capacity	- GB
Display diagonal	- \
Viewfinder type	Electronic
Camcorder type	Handheld camcorder
Supported aspect ratios	17:9
Product color	Black
Video resolutions	1920 x 1080, 2048 x 1080 pixels
Video formats supported	MPEG2, XAVC
Maximum video resolution	2048 x 1080 pixels
Maximum image resolution	- pixels
USB 2.0 ports quantity	1
Component video (YPbPr/YCbCr) out	0
Battery capacity	- mAh
Battery life (max)	- h
Battery technology	-
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Signal-to-Noise Ratio (SNR)	57 dB

Weight and Dimensions

Depth	191 mm
Width	130 mm
Height	125 mm
Weight	2200 g
