Operation
FUNCTION screen hierarchy
The following diagram shows the composition of the FUNCTION screen hierarchy.
The types of icons that can be displayed on the FUNCTION screen can be set using FUNCTION HOOK UP in the SETUP
screen. (For details on FUNCTION HOOK UP, see page 20.)
Basic Operations

Sony RM-TP501 Primary Specifications

Display

liquid crystal size	3.8 inches
display resolution	256 x 200 dots
liquid crystal type	Reflection system (Monochrome type)

Power

power requirements for operation	DC 6V (Type AA alkaline batteries)
power requirements for memory preservation	DC 3V (CR2032 lithium battery)

Weight and Dimensions

maximum external dimensions	160 x 111 x 46 mm
mass	290 g (Main unit only including touch pen)
