REAR COVER
4. Remove left side hook. (Qty: 2)
①
Grip Rear Cover with hand and unhook Rear Cover – Bezel hook using ruler or jig
②
Flex the Rear cover outwards to unhook. Support set with arm.
Note:
Back Chassis-Rear Cover Hook
Rear Cover-Bezel Hook
21
DISASSEMBLY AND REMOVAL CAUTION 75”
