Sony SA-GN10 - General Information; Locating Controls; Circuit Boards Location

33
SA-GN10
SA-GN10
SECTION 1
GENERAL
This section is extracted from
instruction manual.
• LOCATING THE CONTROLS
– Front View (a part) –
– Rear View (a part) –
INPUT
INPUT
For schematic diagrams.
Note:
• All capacitors are in µF unless otherwise noted. (p: pF) 50 WV or
less are not indicated except for electrolytics and tantalums.
• All resistors are in Ω and
1
/
4
W or less unless otherwise specifed.
• C : panel designation.
Note: The components identified by mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number specified.
• A : B+ Line.
• B : B– Line.
•Voltages are dc with respect to ground under no-signal conditions.
no mark : Power on
•Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production
tolerances.
• Signal path.
F : AUDIO
For Printed Wiring Boards:
Note:
• X : parts extracted from the component side.
•
: Pattern from the side which enables seeing.
• Circuit Boads Location
POWER SWITCH board
MAIN board
INPUT board
POWER TRANS board
PANEL board
SECTION 2
DIAGRAMS
CUT OFF FREQ
SUBWOOFER LEVEL
MIN MAX
CUT OFF FREQ
SUBWOOFER LEVEL
50Hz 200Hz
Indicator SUBWOOFER ON/OFF
SUBWOOFER ON/OFF
