SA-VE535H/WMS535/SS-MS535
Ref. No. Location
D201 I-4
D202 H-4
D301 D-3
D302 D-3
D303 F-6
D304 F-4
D501 C-8
D502 E-6
D503 E-6
D504 E-7
D505 E-7
D506 E-5
D507 E-5
D508 C-2
D509 B-4
D510 C-6
D511 B-6
D512 C-5
D513 B-5
D601 I-7
D602 I-7
D603 J-7
D604 I-7
D605 H-7
D606 G-7
(D607) J-9
<D608> G-8
D701 B-3
D702 B-4
D703 A-5
D704 A-5
D801 E-10
IC101 B-2
IC102 C-2
IC201 H-3
IC202 H-1
IC203 H-3
IC204 H-4
IC301 E-2
IC501 C-3
IC701 B-4
Q301 D-3
Q302 D-3
Q303 D-3
Q304 D-2
Q305 D-3
Q306 D-3
Q307 D-4
Q308 E-4
Q309 E-4
Q310 F-4
Q311 E-4
Q401 J-3
Q402 J-3
Q403 J-2
Q404 J-5
Q501 E-5
Q502 E-5
Q503 C-4
Q504 C-4
Q505 C-5
Q506 C-5
Q601 H-7
Q602 G-7
Q701 B-5
Q702 B-6
Q703 B-5
Q704 B-6
Q705 B-6
• Semiconductor
Location
(): Except Singapore model
<>: Singapore model
Note on Schematic Diagram:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ω and
1
/
4
W or less unless otherwise
specified.
• 2 : nonflammable resistor.
• C : panel designation.
Note:
The components identi-
fied by mark 0 or dotted
line with mark 0 are criti-
cal for safety.
Replace only with part
number specified.
Note:
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
• A : B+ Line.
• B : B– Line.
•Voltage is dc with respect to ground under no-signal
(detuned) condition.
•Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
• Signal path.
F : AUDIO
• Abbreviation
CND : Canadian model.
SP : Singapore model.
MY : Malaysia model.
AR : Argentine model.
Note on Printed Wiring Boards:
• X : parts extracted from the component side.
• : Pattern from the side which enables seeing.
• Abbreviation
CND : Canadian model.
SP : Singapore model.
MY : Malaysia model.
AR : Argentine model.
