MK11004V1OHB12NOV
Distributed by
©2012 Sony Corporation. All rights reserved.
Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice.
The values for mass and dimension are approximate.
“Sony”, “make.believe”, “IPELA”, “IPELA ENGINE EX”, “Exmor”, and
“DEPA” are trademarks of Sony Corporation.
All other trademarks are the properties of their respective owners.
SPECIFICATIONS
DIMENSIONS
Network
Recording Software
IMZ-NS100 Series
Recording Server
NSR-500
PC
SNC-VB600
SNC-VB600
HD monitor
SYSTEM CONFIGURATION
54.1 (2 1/4) 145.0 (5 3/4)
44.0 (1 3/4)
55.0 (2 1/4)
150.5 (6)
72.0 (2 7/8)
63.0 (2 1/2)
62.0 (2 7/16)
Side
Front
Rear
Unit: mm (inches)
SNC-VB600B
Camera
Image Sensor 1/3-type progressive scan Exmor CMOS
Image Sensor (Number of Effective Pixels) Approx. 1.37 Megapixels
Signal System NTSC color system / PAL color system (switchable)
Minimum Illumination (50 IRE) Color: 0.05 lx (F1.2, View-DR OFF, VE OFF, AGC ON, 1/30 s, 30 fps)
B/W: 0.04 lx (F1.2, View-DR OFF, VE OFF, AGC ON, 1/30 s, 30 fps)
Minimum Illumination (30 IRE) Color: 0.03 lx (F1.2, View-DR OFF, VE OFF, AGC ON, 1/30 s, 30 fps)
B/W: 0.02 lx (F1.2, View-DR OFF, VE OFF, AGC ON, 1/30 s, 30 fps)
Dynamic Range Equivalent to 130 dB with View-DR technology
S/N Ratio More than 50 dB (Gain 0 dB)
Gain Auto
Shutter Speed 1/1 s to 1/10000 s
Sync System Internal synchronization
Exposure Control Exposure compensation, AGC, Shutter speed, Iris
White Balance ATW, ATW-PRO, Fluorescent lamp, Mercury lamp, Sodium vapour lamp, Metal halide lamp, White LED, One push WB, Manual
Lens CS mount varifocal lens
Zoom Ratio Optical zoom 2.9x, Digital zoom 2x *
3
Powered Focus Yes (Easy Focus)
Horizontal Viewing Angle 100.0° to 35.7°
Vertical Viewing Angle 78.1° to 28.6°
Focal Length f = 2.8 mm to 8.0 mm
F-Number F1.2 (Wide) to F1.95 (Tele)
Minimum Object Distance 300 mm
Horizontal Resolution 600 TV lines (analog video) *
2
Preset Position 8
Tour 5
Camera Features
Day/Night Yes
Wide-D Yes (View-DR)
Image Enhancement Visibility Enhancer (VE)
Noise Reduction XDNR
Image Stabilizer Yes *
3
*
6
Codec Image Size (H x V) 1280 x 1024, 1280 x 960, 1024 x 768, 1280 x 720, 800 x 600, 720 x 576, 720 x 480, 704 x 576, 640 x 480, 352 x 288,
320 x 240 (H.264, JPEG)
Video Compression Format H.264 (High/Main/Baseline Profile), JPEG
Codec Streaming Capability Triple Streaming *
1
, CBR/VBR (selectable) *
4
Maximum Frame Rate H.264: 30 fps (1280 x 1024)
JPEG: 30 fps (1280 x 1024)
Audio
Audio Compression Format G.711/G.726/AAC (16 kHz, 48 kHz)
Scene Analytics
Intelligent Motion Detection Yes
Face Detection Yes *
5
Rule-based Filter DEPA Advanced *
3
Network
Protocols IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, DNS, NTP, RTP/RTCP, RTSP, SMTP, IPv6 *
5
, HTTPS *
4
, SNMP (MIB-2) *
4
ONVIF Conformance Yes (Profile S) *
5
Number of Clients 20
Authenticatoin IEEE 802.1X *
4
Interface
Analog Video Output BNC x1, 1.0 Vp-p, 75 Ω, unbalance, sync negative
Line Input Mini jack (monaural)
Line Output Mini jack (monaural), Maximum output level: 1 Vrms
Network Port 10BASE-T/100BASE-TX (RJ-45)
Sensor Input x 2, make contact, break contact
Alarm Output x 2, 24 V AC/DC, 1 A (mechanical relay outputs electrically isolated from the camera)
Microphone Input Mini jack (monaural)
Card Slots SD Card x 1
System Requirements
Operating System Windows XP (32 bit) Professional Edition
Windows Vista (32 bit) Ultimate, Business Edition
Windows 7 (32/64 bit) Ultimate, Professional Edition
Processor Intel Corei7 2.8 GHz or higher
Memory 2 GB or more
Web Browser Microsoft Internet Explorer Ver. 7.0, Ver. 8.0, Ver. 9.0
Firefox Ver. 3.5 (Plug-in free viewer only)
Safari Ver. 4.0 (Plug-in free viewer only)
Google Chrome Ver. 4.0 (Plug-in free viewer only)
General
Power Requirements PoE system (IEEE 802.3af compliant), DC 12 V ± 10%, AC 24 V ± 20%
Power Consumption 6.0 W max.
Operating Temperature -10 °C to +50 °C (14°F to 122°F)
Starting Temperature 0 °C to 50 °C (32°F to 122°F)
Storage Temperature -20 °C to +60 °C (-4°F to +140°F)
Operating Humidity 20% to 80%
Storage Humidity 20% to 95%
Dimensions (W x H x D) 72 mm x 63 mm x 145 mm (2 7/8 inches x 2 1/2 inches x 5 3/4 inches) (without lens)
72 mm x 63 mm x 197 mm (2 7/8 x 2 1/2 x 7 7/8 inches) (with lens)
Mass Approx. 565 g (1 lb 4 oz) (with lens)
Safety Regulations JATE Technical standard (LAN)
UL2044, IEC60950-1 (CB)
VCCI (Class A), FCC (Class A), IC (Class A)
Emission: EN55022 (Class A) + EN50130-4
Immunity: EN55022 (Class A) + EN55024
Emission: AS/NZS CISPR22 (Class A)
Supplied Accessories CD-ROM (supplied programs) (1), Installation Manual (1), Wire rope (1), Screw M4 (1), DC 12/AC 24V connector (1),
Safety regulations (1)
*1 Triple streaming (any combination with JPEG/H.264, including multiple streams of the same format)
*2 Monitor display ratio 4:3 *3 Version 1.2 or later *4 Version 1.3 or later *5 Version 1.4 or later *6 Default setting: OFF
