10
Specifications
Camera
Image sensor 35 mm full frame Exmor
®
CMOS sensor
Number of Effective Pixels Approx. 12.2 Megapixels
Lens type E-mount lens (option)
Sync System Internal synchronization
Minimum Illumination (30 IRE) 0.004 lx (1/30s, F1.4)
Video
Image Compression Format H.264 (High/Main Profile), JPEG
H.264 (B-picture) supports the resolution below.
3,840 × 2,160
2,880 × 2,160
Maximum Frame Rate H264: 30 fps (3,840 × 2,160)/30 fps (1,920 × 1,080)
JPEG: 2.5 fps (4,240 × 2,832)
Audio
Compression Format G.711 (bit rate: 64 kbps, sampling frequency: 8 kHz)
G.726 (bit rate: 40, 32, 24, 16 kbps, sampling frequency: 8 kHz)
AAC-LC (bit rate: 64 kbps, sampling frequency: 16 kHz)
AAC-LC (bit rate: 128 kbps, sampling frequency: 48 kHz)
Interface
Digital Video Output HDMI (type D) × 1
Microphone Input Mini jack (monaural, 2.2 kΩ, plug-in-power)
Line Input Mini jack (monaural)
Network port 10BASE-T/100BASE-TX (RJ-45)
Alarm input (sensor input) 2 ports (MAKE contact, BREAK contact)
Alarm output 2 ports (solid-state relay Max. AC 12 V/DC 24 V, 0.4 A) (electrically isolated
from the camera)
Wireless LAN terminal Supports the accessory IFU-WLM3 (sold separately)
Memory card slot SD memory card slot (supports SDHC/SDXC memory cards) × 1
General
Power Requirements PoE (Compliant with IEEE802.3af)
DC 12 V ± 25 %, AC 24 V ± 20 %, 50/60 Hz
Power Consumption Max. approx. 16W (including lens)
Operating temperature
When power is turned on
While on
0°C to 50°C
–5°C to +50°C
Storage Temperature –20°C to +60°C
Operating Humidity 20 % to 80 % (no condensation)
Storage Humidity 20 % to 80 % (no condensation)
