SS-C990/CT551/SS880/TS551/WS551
1-1. SS-CT551 (CENTER SPEAKER)
EXPLODED VIEWS
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference num-
ber in the exploded views are not supplied.
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
1 A-4467-953-A AL CENTER ASSY 2 A-4467-961-A BRACKET NET SUB ASSY
1
2
not supplied
To Next Page
