12
SA-VE835ED/WMS835/SS-MS835
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
LED
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
1-684-604-11 LED BOARD
**********
< CONNECTOR >
* CN401 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D402 8-719-061-31 LED SML72420CTH8F (ON/STANDBY)
< RESISTOR >
R402 1-249-421-11 CARBON 2.2K 5% 1/4W
*************************************************************
A-4676-377-A MAIN POWER BOARD, COMPLETE (US,CND,MX)
A-4676-386-A MAIN POWER BOARD, COMPLETE
(AEP,UK,SP,AR,KR)
****************************
1-533-233-11 HOLDER, FUSE
< CAPACITOR >
0C2 1-113-925-11 CERAMIC 0.01uF 20% 250V
C701 1-126-934-11 ELECT 220uF 20% 10V
C702 1-126-948-11 ELECT 100uF 20% 35V
C703 1-126-963-11 ELECT 4.7uF 20% 50V
0C901 1-117-916-11 FILM 0.22uF 275V
0C902 1-113-915-11 CERAMIC 0.001uF 20% 250V
(AEP,UK,SP,AR,KR)
0C903 1-113-915-11 CERAMIC 0.001uF 20% 250V
(AEP,UK,SP,AR,KR)
0C904 1-113-915-11 CERAMIC 0.001uF 20% 250V
(AEP,UK,SP,AR,KR)
0C905 1-117-916-11 FILM 0.22uF 275V
0C906 1-113-915-11 CERAMIC 0.001uF 20% 250V
(US,CND,MX)
0C907 1-113-915-11 CERAMIC 0.001uF 20% 250V
(US,CND,MX)
0C908 1-113-915-11 CERAMIC 0.001uF 20% 250V
(US,CND,MX)
0C910 1-137-994-11 ELECT 820uF 20% 200V
(US,CND,MX)
0C910 1-165-626-11 ELECT 390uF 20% 400V
(AEP,UK,SP,AR,KR)
0C911 1-165-706-91 FILM 0.01uF 5% 630V
C912 1-126-947-11 ELECT 47uF 20% 25V
C913 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP,UK,SP,AR,KR)
C913 1-162-290-31 CERAMIC 470PF 10% 50V
(US,CND,MX)
0C914 1-125-893-11 FILM 680PF 3% 1.5KV
(AEP,UK,SP,AR,KR)
0C914 1-136-555-11 FILM 0.0022uF 5% 630V
(US,CND,MX)
C915 1-162-290-31 CERAMIC 470PF 10% 50V
0C916 1-117-703-11 CERAMIC 0.0047uF 250V
C917 1-117-832-11 FILM 4700PF 3% 1.5KV
(AEP,UK,SP,AR,KR)
C917 1-136-559-11 FILM 0.0047uF 5% 630V
(US,CND,MX)
C918 1-115-361-11 ELECT 6800uF 20% 50V
C919 1-126-951-11 ELECT 470uF 20% 35V
C920 1-126-951-11 ELECT 470uF 20% 35V
C922 1-136-153-00 FILM 0.01uF 5% 50V
C932 1-136-165-00 FILM 0.1uF 5% 50V
C933 1-136-165-00 FILM 0.1uF 5% 50V
C934 1-126-935-11 ELECT 470uF 20% 16V
C935 1-126-935-11 ELECT 470uF 20% 16V
C936 1-136-165-00 FILM 0.1uF 5% 50V
C937 1-136-165-00 FILM 0.1uF 5% 50V
C938 1-164-159-21 CERAMIC 0.1uF 50V
C939 1-164-159-21 CERAMIC 0.1uF 50V
C940 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C941 1-161-494-00 CERAMIC 0.022uF 25V
C942 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
CN903 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
CN904 1-757-829-11 CORD, CONNECTION
* CN906 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN907 1-757-828-11 CORD, CONNECTION
* CN909 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D701 8-719-911-19 DIODE 1SS119-25
0 D901 8-719-022-92 DIODE RBV-604 (US,CND,MX)
0 D901 8-719-084-58 DIODE RBV-406 (AEP,UK,SP,AR,KR)
D902 8-719-080-26 DIODE SARS01V0
D903 8-719-075-11 DIODE AG01ZV0
D904 8-719-110-17 DIODE RD10ES-B2
D905 8-719-079-18 DIODE MTZJ-T-72-20A
D906 8-719-075-11 DIODE AG01ZV0
D907 8-719-075-11 DIODE AG01ZV0
D908 8-719-075-11 DIODE AG01ZV0
D909 8-719-049-98 DIODE FML-G14S (AEP,UK,SP,AR,KR)
D909 8-719-058-38 DIODE FMN-G12S (US,CND,MX)
D910 8-719-064-47 DIODE RN1Z-LF-B1
D911 8-719-064-47 DIODE RN1Z-LF-B1
D919 8-719-200-82 DIODE 11ES2
D920 8-719-200-82 DIODE 11ES2
D921 8-719-911-19 DIODE 1SS119-25
D922 8-719-043-76 DIODE AK04V0
< TERMINAL BOARD >
EP901 1-537-770-21 TERMINAL BOARD, GROUND
EP902 1-537-770-21 TERMINAL BOARD, GROUND
EP903 1-537-770-21 TERMINAL BOARD, GROUND
EP904 1-537-770-21 TERMINAL BOARD, GROUND
MAIN POWER
Ver 1.1
