Sony STR-AZ3000ES - Page 265

Help Guide
Multi Channel AV Receiver
STR-AZ7000ES/STR-AZ5000ES/STR-AZ3000ES
Relations between sound fields and speaker outputs
The list below shows which speaker outputs sound when a certain sound field is selected.
2-channel content
Meaning of symbols in the table
-: No sound is output.
◎: Outputs sound.
○: Outputs sound depending on the speaker pattern setting and content to be played back.
●: For Dolby and DTS audio streams, outputs sound depending on the speaker pattern setting. No sound is output for Linear PCM, DSD, or AAC.
A subwoofer is connected.
Speaker pattern with a subwoofer ([x.1]) is set.
A subwoofer is connected.
Speaker pattern with a subwoofer ([x.1]) is set.
[Manual Speaker Settings] - [Size] in [Speaker Settings] menu is set to [Small].
Multi-channel content
Meaning of symbols in the table
-: No sound is output.
◎: Outputs sound.
○: Outputs sound depending on the speaker pattern setting and content to be played back.
Note
When no sound is heard, check that all the speakers are securely connected to the correct speaker terminals and the correct speaker pattern is selected.
5-037-021-11(1) Copyright 2022 Sony Corporation
Sound field
Display
panel
Front
speakers
Center
speaker
TV Center
speaker
Surround
speakers
Surround back
speakers
Subwoofer
Height
speakers
2CH/MULTI
2ch Stereo 2CH STEREO ◎ - - - - - -
Multi Stereo MULTI ST. ◎ ○ ○ ○ ○ ○ (*1) ○
Direct (Analog input) DIRECT ◎ - - - - - -
Direct (Others) DIRECT ◎ - - - - ○ (*2) -
A.F.D. (Auto Format
Decoding)
A.F.D. ◎ ● ● ● ● ○ (*2) ●
MOVIE
A.F.D. Movie A.F.D. MOVIE ◎ ○ ○ ○ ○ ○ (*1) ○
Dolby Mode
DOLBY
MODE
◎ ○ ○ ○ ○ ○ (*1) ○
DTS:X Mode DTS:X MODE ◎ ○ ○ ○ ○ ○ (*1) ○
MUSIC Audio Enhancer
A.
ENHANCER
◎ - - - - ○ (*2) -
Sound is output when the following conditions are met:
*1
Sound is output when the following conditions are met:
*2
Sound field
Display
panel
Front
speakers
Center
speaker
TV Center
speaker
Surround
speakers
Surround back
speakers
Subwoofer
Height
speakers
2CH/MULTI
2ch Stereo 2CH STEREO ◎ - - - - - -
Multi Stereo MULTI ST. ◎ ○ ○ ○ ○ ○ ○
Direct DIRECT ◎ ○ ○ ○ ○ ○ ○
A.F.D. (Auto Format
Decoding)
A.F.D. ◎ ○ ○ ○ ○ ○ ○
MOVIE
A.F.D. Movie A.F.D. MOVIE ◎ ○ ○ ○ ○ ○ ○
Dolby Mode
DOLBY
MODE
◎ ○ ○ ○ ○ ○ ○
DTS:X Mode DTS:X MODE ◎ ○ ○ ○ ○ ○ ○
MUSIC Audio Enhancer
A.
ENHANCER
◎ ○ ○ ○ ○ ○ ○
176
