Specifications
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
(USA Models Only):
STR-AZ7000ES
With 8  loads, both channels driven, from 20Hz – 20000Hz; rated
140W per channel minimum RMS power in stereo mode, with no more
than 0.09% total harmonic distortion from 250mW to rated output.
STR-AZ5000ES
With 8  loads, both channels driven, from 20Hz – 20000Hz; rated
120W per channel minimum RMS power in stereo mode, with no more
than 0.09% total harmonic distortion from 250mW to rated output.
STR-AZ3000ES
With 8  loads, both channels driven, from 20Hz – 20000Hz; rated 110W
per channel minimum RMS power in stereo mode, with no more than
0.09% total harmonic distortion from 250mW to rated output.
Amplifier section
1)2)
STR-AZ7000ES
Rated Power Output at Stereo Mode
(8 ohms, 20 Hz – 20 kHz, THD 0.09%): 140 W + 140 W
Reference Power Output
(8 ohms, 1 kHz, THD 0.9%)
FRONT: 150 W + 150 W
CENTER: 150 W
SURROUND: 150 W + 150 W
SURROUND BACK: 150 W + 150 W
HEIGHT 1: 150 W + 150 W
HEIGHT 2: 150 W + 150 W
HEIGHT 3: 150 W + 150 W
STR-AZ5000ES
Rated Power Output at Stereo Mode
(8 ohms, 20 Hz – 20 kHz, THD 0.09%): 120 W + 120 W
Reference Power Output
(8 ohms, 1 kHz, THD 0.9%)
FRONT: 130 W + 130 W
CENTER: 130 W
SURROUND: 130 W + 130 W
SURROUND BACK: 130 W + 130 W
HEIGHT 1: 130 W + 130 W
HEIGHT 2: 130 W + 130 W
STR-AZ3000ES
Rated Power Output at Stereo Mode
(8 ohms, 20 Hz – 20 kHz, THD 0.09%): 110 W + 110 W
Reference Power Output
(8 ohms, 1 kHz, THD 0.9%)
FRONT: 120 W + 120 W
CENTER: 120 W
SURROUND: 120 W + 120 W
SURROUND BACK: 120 W + 120 W
HEIGHT: 120 W + 120 W
1)
Measured under the following conditions:
Power requirements: 120V AC, 60Hz
2)
Depending on the sound field settings and the source, there may be
no sound output.
Frequency response
Analog
10 Hz – 100 kHz, ±3dB (with sound field, equalizer and 360SSM
bypassed)
Input
Analog
Sensitivity: 150 mV/50 kilohms
S/N
3)
: 105 dB (A, 500 mV
4)
)
Digital (Coaxial)
Impedance: 75 ohms
S/N: 96 dB (A, 20 kHz LPF)
Digital (Optical)
S/N: 96 dB (A, 20 kHz LPF)
continued
