Amplifier section
Continuous RMS power output (8 ohms, at 40 Hz - 20 kHz less than
0.8% total harmonic distortion) (FRONT)
STR-D615:60 W + 60 W
STR-D515:50 W + 50W
Dynamic power (at 1 kHz IHF) (FRONT)
STR-D615:80 W + 80 W (8 ohms), 110 W + 110 W (4 ohms)
STR-D515:70 W + 70 W (8 ohms), 100 W + 100 W (4 ohms)
Harmonic distortion
Less than 0.8% at rated output
SUR (surround) MODE (8 ohms, less than 0.8% total harmonic
distortion
STR,D615
60W +60W
20W
FRONT
CENTER (only in the
DOLBY mode)
REAR 20 W 20 W
STR-D515
50 W +50 W
20W
Frequency response
PHONO: RIAA equalization curve +0.5 dB
CD
VIDEO 10 Hz - 50 kHz _+1dB
TAPE
Inputs
Sensitivity
PHONO 2.5 mV
CD 300 mV
VIDEO, 200 mV
TV/LD
TAPE/MD
Outputs
REC OUT, VIDEO
(AUDIO) OUT
HEADPHONES
Impedance
50 kilohms
50 kilohms
S/N (weighting
network, input level)
74dB
72 dB* (A, 2.5 mV)
95 dB
80 dB* (A, 200 mV)
* '78 IHF
Voltage 200 mV
Impedance 10 kilohms
Accepts low and high impedance
headphones
Tone controls
BASS: +10 dB at 100 Hz
TREBLE: +8 dB at 10 kHz
Muting
-20 dB
LOW BOOST
+7 dB at 70 Hz
22
Video section
INPUT VIDEO,
TV/LD
1 Vp-p 75 ohms
OUTPUT VIDEO 1 Vp-p 75 ohms
iMONITOR
Tuner section
Tuning range
Antenna
terminals
Sensitivity at
46 dB quieting
Usable
sensitivity
Signal-to-noise
ratio
Harmonic
distortion
Sel_o.tivity
• jut
Separation
Frequency
response
FM l_uner section
i87.5- 108 MHz
300 ohms, balanced
75 ohms, unbalanced
18.3 dBf, 4.5 laV (mono)
38.3 dBf, 45 IxV (stereo)
11.2 dBf, 2 laV (IHF)
70 dB (mono)
66 dB (stereo)
0.3% (mono), 0.5%
(stereo) at I kHz
60 dB at 400 kHz
45 dB at I kHz
30 Hz -- 15 kHz
+ 0.5
-2 dB
*! AM tuner section
531 -- 1,602 kHz
External antenna
terminal
Loop antenna:
500 btV (at 999 kHz)
54 dB (at 50 mV/m)
0.5% (at 50 mV/m,
400 Hz)
30dB at 9kHz
General
System
Tuner section: PLL quartz-locked digital synthesizer
system
Preamplifier section: low-noise NF type equalizer amp
Power amplifier section: pure complementary SEPP
Power requirements
240 V AC, 50/60 Hz (for U.K. model)
240 V AC, 50 Hz (for Australian model)
Power consumption
160 W (STR-D615)
135 W (STR-D515)
In standby condition: 5 W
AC outlet
One switched (100 W Max.)
Dimensions
Approx. 430 x 135 x 295 mm (w/h/d)
(17 x 5 3/8 x 11 s/8 inches)
including projecting parts and controls
Mass
Approx. 6.9 kg (15 lb 4 oz) (STR-D615)
Approx. 6.4 kg (14 lb 2 oz) (STR-D515)
Accessories supplied
FM wire antenna (1)
AM loop antenna (1)
Remote Commander RM-P342 (1)
Sony batteries SUM-3(NS) (2)
Design and specifications are subject to change without notice.
Note
This appliance conforms with EEC Directive 87/308/EEC regarding
interference suppression.
