STR-DH520
Sony ® 7.1 Channel 3D AV Receiver
Please visit the Dealer Source for current
information at www.sony.com/dealersource
Features
Video Features
HDMI™
3D over HDMI: Yes
Audio Return Channel: Yes
Audio Widget: Yes
BRAVIA(r) SYNC(TM) (CEC Control): Yes
HDMI Pass Through: Yes
HDMI(tm) video output capability:
1080P/24P/Deep Color/x.v.Color (xvYCC)
Theater Mode Selector: Yes
A/V Sync
A/V SYNC: Yes(Fixed)
A/V Sync Sampling Freequency: 48kHz
A/V Sync Time(msec): 60msec
A/V Sync auto mode: No
Amplifier/Receiver
Amplifier
4 Ohm/8 Ohm Switching: 8 Ohm only
Analog Direct: Yes
Night Mode: Yes
Speaker Selector: A Speakers only
Speaker Terminal: Front(Screw)/Others
(Push)
Sub Woofer X' Over: 17 points (40 - 200Hz)
Advanced Auto Volume: Yes
Number of amp. channels: 7ch (Sub must
be self powered)
Other
Additional
Assignable Component Video IN: Yes
Assignable HDMI Video IN: Yes
Auto Standby: Yes
Digital Input Assign: Yes
Pin Jack: Nickel
Power Requirement: 120V 60Hz
Remote Commander: RM - AAU104
Sleep Timer: Yes
Specifications
Amplifier/Receiver
Output Power
(8Ohms 1kHz) THD: 1%
(8Ohms 20 - 20kHz) THD: 0.09%
8Ohms 1kHz: 100W + 100W
8Ohms 20 - 20kHz: 90W + 90W
Output Power (JEITA 10%)/ Rated Output
Power(0.09% 20Hz - 20kHz 4Ohm): 10%
Output Power (JEITA 10%)/Rated Output
Power(0.09% 20Hz - 20kHz 8Ohm): 130W
Decoding Format(s)
96k/24Bit PCM: Yes
Dolby Dual Mono: Yes
LPCM (2CH/5.1CH/7.1CH) thru HDMI: Yes
(Yes/Yes/Yes)
DTS / DTS - ES (Matrix6.1 / Discrete6.1):
Yes/Yes
DTS 96/24/ DTS NEO:6: Yes/Yes
DTS HD MA/ DTS HD HR: Yes/Yes
Dolby Digital EX/ Dolby Digital: Yes/Yes
Dolby Prologic/II /Iix /Iiz: Yes/Yes/Yes/Yes
Dolby TruHD/Dolby Digital +: Yes/Yes
Tuner
Auto Tuning: Yes
Direct Tuning: Yes(RM)
Station Name: Yes
FM/AM: Yes/Yes
Preset Channel (Sirius/XM/FM/AM): TTL60
(30FM/30AM)
Tone Control
Front (Bass/Treble): Yes/Yes
Sound Field
2ch: Yes
A.F.D. Auto: Yes
Analog Direct: Yes
Church: Yes
Concert Hall: Yes
Digital Concert Hall A/B: Yes
HD - D.C.S.: Yes
Headphone 2ch: Yes
Headphone Direct: Yes
Headphone Multi: Yes
Jass Club: Yes
Multi Stereo: Yes
Neo:6 Music: Yes
PLII Movie: Yes
PLII Music: Yes
PLIIx Movie: Yes
PLIIx Music: Yes
PLIIz Height: Yes
Portable Audio Enhancer: Yes
Sports: Yes
Stadium: Yes
Audio Input
Analog Audio In (Inc TV CEC)/Out (excl.
tuner)/TV (CEC): 2/Yes
Coax.: 1
Opt. In/Out/TV (CEC): incl Front input & TV
(CEC): 2/yes
Analog Stereo Mini Jack: 1(for Portable)
Audio Output
Analog Audio Out: 0
Headphone Out: Yes(Gold)
Pre Out (Subwoofer): 1
Speaker Out
Center: Yes
Front A (L/R): Yes
Surround (L/R): Yes
Surround Back (L/R): Yes
Front High (L/R)/ Surround Back for
Common Use: Yes
Video Input
A/V In: Including Front AV: 2
Component Video In: 2
HDMI In (Front In): 4
Video Output
A/V Out (inc. Monitor Out): 1
Component Video Out (inc. Monitor Out):
1
HDMI Out: 1
1. 3D viewing requires 3D content, 3D HDTV, a high speed HDMI ™ cable
(supporting at least 10.2 Gbps) connection, and other 3D accessories
(including 3D glasses).
2. Dolby® True - HD and dts ® - HD Master Audio decoding require HDMI ™
cable and capable source device (both sold separately).
3. Requires connection via HDMI ™ cable (sold separately) to equivalent
HDTV. Image and sound quality will vary depending on source.
4. Works with other BRAVIA® Sync or Theatre Sync™ labeled home
audio/video products when connected via HDMI ™ interface.
5. Can be used only when [sound bar, receiver, etc.] is connected to a
Sony XBR - EX620, EX630, EX720, EX820, EX830, NX830, HX820, HX830,
or HX930 series BRAVIA HDTV via HDMI™ cable (sold separately).
6. HDMI™ cable required, sold separately.
7. Requires sources connected with HDMI ™ cables (sold separately).
Sound Quality will vary depending on source.
