– 48 –
< CONNECTOR >
* CN902 1-569-503-11 PIN, CONNECTOR 8P
< DIODE >
D903 8-719-987-63 DIODE 1N4148M
D953 8-719-987-63 DIODE 1N4148M
< IC >
IC901 8-749-921-68 IC STK-4231MK2 (US,CND)
IC901 8-749-900-34 IC STK-4182MK2 (EXCEPT US,CND)
< TRANSISTOR >
Q901 8-729-661-94 TRANSISTOR RT1N141SK-TP
Q902 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q952 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R901 1-249-417-11 CARBON 1K 5% 1/4W
R902 1-249-437-11 CARBON 47K 5% 1/4W
R903 1-249-412-11 CARBON 390 5% 1/4W
(US,CND)
R903 1-249-413-11 CARBON 470 5% 1/4W
(EXCEPT US,CND)
R904 1-249-437-11 CARBON 47K 5% 1/4W
R906 1-249-429-11 CARBON 10K 5% 1/4W
R907 1-249-429-11 CARBON 10K 5% 1/4W
R908 1-249-429-11 CARBON 10K 5% 1/4W
R909 1-249-429-11 CARBON 10K 5% 1/4W
R910 1-249-397-11 CARBON 22 5% 1/4W
R911 1-249-397-11 CARBON 22 5% 1/4W
R913 1-249-417-11 CARBON 1K 5% 1/4W
R914 1-249-431-11 CARBON 15K 5% 1/4W
R915 1-249-441-11 CARBON 100K 5% 1/4W
! R920 1-217-151-00 METAL PLATE 0.22 F
! R932 1-212-881-11 FUSIBLE 100 5% 1/4W F
R933 1-249-421-11 CARBON 2.2K 5% 1/4W
R934 1-249-421-11 CARBON 2.2K 5% 1/4W
R935 1-249-421-11 CARBON 2.2K 5% 1/4W
R936 1-249-421-11 CARBON 2.2K 5% 1/4W
R937 1-249-437-11 CARBON 47K 5% 1/4W
R938 1-249-441-11 CARBON 100K 5% 1/4W
R939 1-249-433-11 CARBON 22K 5% 1/4W
R940 1-249-433-11 CARBON 22K 5% 1/4W
R941 1-249-429-11 CARBON 10K 5% 1/4W
R942 1-249-413-11 CARBON 470 5% 1/4W
! R943 1-212-881-11 FUSIBLE 100 5% 1/4W F
R951 1-249-417-11 CARBON 1K 5% 1/4W
R952 1-249-437-11 CARBON 47K 5% 1/4W
R953 1-249-412-11 CARBON 390 5% 1/4W
(US,CND)
R953 1-249-413-11 CARBON 470 5% 1/4W
(EXCEPT US,CND)
R954 1-249-437-11 CARBON 47K 5% 1/4W
R956 1-249-429-11 CARBON 10K 5% 1/4W
R957 1-249-429-11 CARBON 10K 5% 1/4W
R958 1-249-429-11 CARBON 10K 5% 1/4W
R959 1-249-429-11 CARBON 10K 5% 1/4W
R960 1-249-397-11 CARBON 22 5% 1/4W
R961 1-249-397-11 CARBON 22 5% 1/4W
R963 1-249-417-11 CARBON 1K 5% 1/4W
R964 1-249-431-11 CARBON 15K 5% 1/4W
R965 1-249-441-11 CARBON 100K 5% 1/4W
! R970 1-217-151-00 RES, METAL PLATE 0.22 F
! R974 1-212-849-00 FUSIBLE 4.7 5% 1/4W F
R980 1-247-807-31 CARBON 100 5% 1/4W
************************************************************
* A-4389-758-A POWER (B) BOARD, COMPLETE (US)
* A-4390-467-A POWER (B) BOARD, COMPLETE (CND)
* A-4390-470-A POWER (B) BOARD, COMPLETE
(E,EA,HK,AR,AUS,JE)
* A-4390-473-A POWER (B) BOARD, COMPLETE (MY)
* A-4390-476-A POWER (B) BOARD, COMPLETE (SP)
* A-4390-768-A POWER (B) BOARD, COMPLETE (TH)
**************************
< CAPACITOR >
C4001 1-124-925-11 ELECT 2.2uF 20% 100V
C4002 1-162-286-31 CERAMIC 220PF 10% 50V
C4003 1-162-282-31 CERAMIC 100PF 10% 50V
C4004 1-126-964-11 ELECT 10uF 20% 50V
C4005 1-126-964-11 ELECT 10uF 20% 50V
C4006 1-136-165-00 FILM 0.1uF 5% 50V
C4007 1-136-165-00 FILM 0.1uF 5% 50V
C4010 1-126-967-11 ELECT 47uF 20% 50V
C4011 1-126-965-11 ELECT 22uF 20% 50V
C4012 1-104-664-11 ELECT 47uF 20% 25V
C4013 1-162-306-11 CERAMIC 0.01uF 30% 16V
C4051 1-124-925-11 ELECT 2.2uF 20% 100V
C4052 1-162-286-31 CERAMIC 220PF 10% 50V
C4053 1-162-282-31 CERAMIC 100PF 10% 50V
C4054 1-126-964-11 ELECT 10uF 20% 50V
C4055 1-126-964-11 ELECT 10uF 20% 50V
C4056 1-136-165-00 FILM 0.1uF 5% 50V
C4057 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
* CN4002 1-569-503-11 PIN, CONNECTOR 8P
< DIODE >
D4001 8-719-013-84 DIODE UZ-24BSD (US,CND)
D4001 8-719-013-83 DIODE UZ-22BSD-TP
(EXCEPT US,CND,TH)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
POWER (B)
POWER (A)
