– 49 –
D4001 8-719-013-85 DIODE UZ-22BSD-TA(TH)
< IC >
IC4001 8-749-920-19 IC STK-4122-2-K
< TRANSISTOR >
Q4001 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q4010 8-729-620-05 TRANSISTOR 2SC2603-EF
Q4051 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R4001 1-249-417-11 CARBON 1K 5% 1/4W
R4002 1-249-437-11 CARBON 47K 5% 1/4W
R4003 1-249-413-11 CARBON 470 5% 1/4W
R4004 1-249-437-11 CARBON 47K 5% 1/4W
R4006 1-249-425-11 CARBON 4.7K 5% 1/4W
R4007 1-249-425-11 CARBON 4.7K 5% 1/4W
R4008 1-249-425-11 CARBON 4.7K 5% 1/4W
R4009 1-249-425-11 CARBON 4.7K 5% 1/4W
R4010 1-249-441-11 CARBON 100K 5% 1/4W
R4011 1-249-441-11 CARBON 100K 5% 1/4W
R4012 1-249-441-11 CARBON 100K 5% 1/4W
R4013 1-249-397-11 CARBON 22 5% 1/4W
R4014 1-249-397-11 CARBON 22 5% 1/4W
! R4020 1-217-151-00 METAL PLATE 0.22 F
! R4021 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R4022 1-212-881-11 FUSIBLE 100 5% 1/4W F
R4023 1-249-425-11 CARBON 4.7K 5% 1/4W
R4024 1-249-429-11 CARBON 10K 5% 1/4W
R4051 1-249-417-11 CARBON 1K 5% 1/4W
R4052 1-249-437-11 CARBON 47K 5% 1/4W
R4053 1-249-413-11 CARBON 470 5% 1/4W
R4054 1-249-437-11 CARBON 47K 5% 1/4W
R4056 1-249-425-11 CARBON 4.7K 5% 1/4W
R4057 1-249-425-11 CARBON 4.7K 5% 1/4W
R4058 1-249-425-11 CARBON 4.7K 5% 1/4W
R4059 1-249-425-11 CARBON 4.7K 5% 1/4W
R4060 1-249-441-11 CARBON 100K 5% 1/4W
R4061 1-249-441-11 CARBON 100K 5% 1/4W
R4062 1-249-441-11 CARBON 100K 5% 1/4W
R4063 1-249-397-11 CARBON 22 5% 1/4W
R4064 1-249-397-11 CARBON 22 5% 1/4W
! R4070 1-217-151-00 METAL PLATE 0.22 F
************************************************************
* 1-660-121-11 SENSOR BOARD
*************
< CAPACITOR >
C651 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN652 1-506-468-11 PIN, CONNECTOR 3P
< IC >
IC651 8-759-947-34 IC LM35DZ
************************************************************
* 1-660-122-11 SP BOARD
*********
< CONNECTOR >
* CN6003 1-569-501-11 PIN, CONNECTOR 6P
< JACK >
J901 1-774-785-11 JACK, PIN 1P (SPEAKER WOOFER)
< TERMINAL >
TM902 1-537-510-11 TERMINAL BOARD (SPEAKER) (6P)
(FRONT SPEAKER L/R +/–)
(CENTER SPEAKER +/–)
************************************************************
A-4303-547-A TCB BOARD, COMPLETE (US,CND)
A-4303-499-A TCB BOARD, COMPLETE (E3,EA,MY,SP,HK)
A-4303-526-A TCB BOARD, COMPLETE (E2,AR,AUS)
A-4303-528-A TCB BOARD, COMPLETE (JE)
A-4304-992-A TCB BOARD, COMPLETE (TH)
********************
< CAPACITOR >
C1 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C2 1-126-967-11 CAP, ELECT 47uF 20% 10V
C3 1-163-038-91 CAP, CERAMIC 0.1uF 25V
C5 1-163-031-11 CAP, CERAMIC 0.01uF 50V
C6 1-163-038-91 CAP, CERAMIC 0.1uF 25V
C7 1-101-004-00 CAP, CERAMIC 0.01uF
C8 1-163-031-11 CAP, CERAMIC 0.01uF 50V
C9 1-163-031-11 CAP, CERAMIC 0.01uF 50V
C10 1-163-031-11 CAP, CERAMIC 0.01uF 50V
C11 1-163-038-91 CAP, CERAMIC 0.1uF 25V
(E3,EA,MY,SP,HK,JE)
C11 1-216-295-91 METAL CHIP 0 5% 1/10W
(US,CND,E2,AUS,AR,TH)
C14 1-163-038-91 CAP, CERAMIC 0.1uF 25V
(E3,EA,MY,SP,HK,JE)
C15 1-136-162-00 CAP, METALIZED FILM 0.056uF
(E3,EA,MY,SP,HK,JE)
C16 1-163-038-91 CAP, CERAMIC 0.1uF 25V
C17 1-163-031-11 CAP, CERAMIC 0.01uF 50V
(E3,EA,MY,SP,HK,JE)
C18 1-163-088-00 CERAMIC CHIP 5PF 50V
(E3,EA,MY,SP,HK,JE)
C21 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
POWER (B)
SENSOR
SP
TCB
