— 22 —
TA-F3000/F3000ES
Sony Corporation
Home A&V Products Company
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< IC >
IC905 8-749-923-43 IC GP1U57XB
**************************************************************
* 1-663-766-11 TONE BOARD
**********
< CAPACITOR >
C301 1-130-477-00 MYLAR 0.0033uF 5% 50V
C302 1-136-155-00 FILM 0.015uF 5% 50V
C303 1-136-157-00 FILM 0.022uF 5% 50V
C304 1-136-165-00 FILM 0.1uF 5% 50V
C401 1-130-477-00 MYLAR 0.0033uF 5% 50V
C402 1-136-155-00 FILM 0.015uF 5% 50V
C403 1-136-157-00 FILM 0.022uF 5% 50V
C404 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
CN301 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
< RESISTOR >
R301 1-259-884-11 CARBON 4.7M 5% 1/4W
R302 1-260-004-11 CARBON MELF 4.7K 2% 1/8W
R303 1-259-997-11 CARBON MELF 1.5K 2% 1/8W
R304 1-259-884-11 CARBON 4.7M 5% 1/4W
R305 1-260-012-11 CARBON MELF 22K 2% 1/8W
R306 1-260-004-11 CARBON MELF 4.7K 2% 1/8W
R401 1-259-884-11 CARBON 4.7M 5% 1/4W
R402 1-260-004-11 CARBON MELF 4.7K 2% 1/8W
R403 1-259-997-11 CARBON MELF 1.5K 2% 1/8W
R404 1-259-884-11 CARBON 4.7M 5% 1/4W
R405 1-260-012-11 CARBON MELF 22K 2% 1/8W
R406 1-260-004-11 CARBON MELF 4.7K 2% 1/8W
< VARIABLE RESISTOR >
RV301 1-225-368-11 RES, VAR, CARBON 250K/250K (BALANCE)
RV302 1-225-369-11 RES, VAR, CARBON 250K/250K (TREBLE)
RV303 1-225-370-11 RES, VAR, CARBON 900K/900K (BASS)
**************************************************************
* 1-663-767-11 VOL BOARD
*********
< CAPACITOR >
C305 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
* CN304 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
* CN305 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN306 1-564-505-11 PLUG, CONNECTOR 2P
< VARIABLE RESISTOR >
RV304 1-225-367-11 RES, VAR, CARBON 120K/120K (VOLUME)
**************************************************************
MISCELLANEOUS
*************
12 1-777-740-11 WIRE (FLAT TYPE) (4 CORE)
13 1-777-739-11 WIRE (FLAT TYPE) (9 CORE)
58 1-506-113-00 SHORT PLUG
! CNP1 1-558-568-21 CORD, POWER
! T801 1-431-369-11 TRANSFORMER, POWER
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-473-956-11 REMOTE COMMANDER (RM-S3000)
3-858-906-11 MANUAL, INSTRUCTION
(ENGLISH, FINNISH, SPANISH, PORTUGUESE,
CHINESE)
3-858-906-21 MANUAL, INSTRUCTION
(GERMAN, DUTCH, ITALIAN, SWEDISH)
(AEP,UK)
4-987-064-01 COVER, BATTERY (For RM-S3000)
**************************************************************
**************
HARDWARE LIST
**************
#1 7-621-259-25 SCREW +P 2.6X4
#2 7-685-871-01 SCREW +BVTT 3X6 (S)
#3 7-682-548-04 SCREW +P 3X8
#4 7-685-872-09 SCREW +BVTT 3X8 (S)
#5 7-685-880-09 SCREW +BVTT 4X6 (S)
#6 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
#7 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#8 7-685-874-09 SCREW +BVTT 3X12 (S)
#9 7-682-548-09 SCREW (3X8)
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number speci-
fied.
9-960-935-11
97D0973-1
Printed in Japan © 1997. 4
Published by General Engineering Dept.
(Shibaura)
