– 31 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN POWER SW TAPE MONITOR
< SWITCH >
S1 1-571-112-21 SWITCH, PUSH (1 KEY) (I/u)
S803 1-571-112-21 SWITCH, PUSH (1 KEY) (EON LINK) (FE530R)
**************************************************************
* 1-673-102-11 TAPE MONITOR BOARD (FE530R)
*******************
< LED >
D823 8-719-301-49 LED SEL2810A (TAPE1 MONITOR)
< SWITCH >
S802 1-554-303-21 SWITCH, TACTILE (TAPE1 MONITOR)
**************************************************************
MISCELLANEOUS
***************
! 111 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
!CP1 1-575-651-21 CORD, POWER
! T1 1-433-621-11 TRANSFORMER, POWER (FE230)
! T1 1-431-802-11 TRANSFORMER, POWER (FE530R)
! T1 1-431-803-11 TRANSFORMER, POWER (FE330R)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-880-09 SCREW +BVTT 4X6 (S)
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#4 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
#5 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-473-655-31 REMOTE COMMANDER (RM-S325)
(FE330R/FE530R)
3-862-730-11 MANUAL, INSTRUCTION (ENGLISH)
(FE330R: UK/FE530R: UK)
3-866-240-11 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, SPANISH, PORTUGUESE)
(FE230/FE330R: AEP/FE530R: AEP)
3-866-240-21 MANUAL, INSTRUCTION
(GERMAN, DUTCH, SWEDISH, ITALIAN)
(FE230/FE330R: AEP/FE530R: AEP)
3-866-240-41 MANUAL, INSTRUCTION
(ENGLISH, POLISH, RUSSIAN)
(FE330R: EE/FE530R: EE)
4-981-643-01 COVER, BATTERY (for RM-S325)
(FE330R/FE530R)
R904 1-247-751-11 CARBON 820 5% 1/2W
(FE530R)
R905 1-247-750-11 CARBON 680 5% 1/2W
(FE230/FE330R)
R905 1-247-751-11 CARBON 820 5% 1/2W
(FE530R)
R907 1-247-752-11 CARBON 1K 5% 1/2W
(FE230/FE330R)
R907 1-247-753-11 CARBON 1.2K 5% 1/2W
(FE530R)
R908 1-247-752-11 CARBON 1K 5% 1/2W
(FE230/FE330R)
R908 1-247-753-11 CARBON 1.2K 5% 1/2W
(FE530R)
R910 1-247-725-11 CARBON 10K 5% 1/4W
R912 1-247-725-11 CARBON 10K 5% 1/4W
R916 1-247-835-11 CARBON 1.5K 5% 1/4W
(FE330R/FE530R)
< RELAY >
RY101 1-515-614-11 RELAY (FE530R)
RY601 1-515-920-11 RELAY (24V)
< TERMINAL >
TM301 1-537-894-11 TERMINAL BOARD (SP) (SPEAKERS)
(FE330R/FE530R)
TM301 1-694-593-11 TERMINAL BOARD (SP) (SPEAKERS) (FE230)
* TM302 1-537-738-21 TERMINAL, EARTH
**************************************************************
* 1-673-099-11 POWER SW BOARD (FE330R/FE530R)
****************
* 4-211-967-01 HOLDER (LED)
< CONNECTOR >
CN807 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
< LED >
D821 8-719-301-49 LED SEL2810A (EON LINK) (FE530R)
D822 8-719-302-45 LED SEL1210S (STANDBY)
< IC >
IC803 8-749-014-66 IC NJL56H400A (g)
< TRANSISTOR >
Q809 8-729-029-66 TRANSISTOR DTC114ESA (FE530R)
Q812 8-729-620-05 TRANSISTOR 2SC2603-EF (FE530R)
Q813 8-729-620-05 TRANSISTOR 2SC2603-EF (FE530R)
< RESISTOR >
R831 1-249-399-11 CARBON 33 5% 1/4W
(FE530R)
R833 1-247-839-11 CARBON 2.2K 5% 1/4W
R835 1-247-855-11 CARBON 10K 5% 1/4W
(FE530R)
R836 1-247-847-11 CARBON 4.7K 5% 1/4W
(FE530R)
R838 1-249-407-11 CARBON 150 5% 1/4W
(FE530R)
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
