SECTION 1
GENERAL
This section is extracted from
instruction manual.
LOCATION OF CONTROLS
• Front View
1 I/u button
2 Remote sensor (TA-FE330R/FE530R)
3 EON LINK button and indicator
(TA-FE530R)
4 PHONES jack
5 SPEAKERS switch
6 BASS dial
7 TREBLE dial
8 BALANCE dial
9 LOUDNESS button
0 INPUT SELECTOR
!¡ SOURCE DIRECT button
(TA-FE330R/FE530R)
!™ VOLUME dial
!£ TAPE1 MONITOR switch
(TA-FE530R)
1
2
3 4
5 6 7
8 9 !º !¡ !™
!£
• Rear View
