Sony TC-D5 User Manual

Sigan
@ Should any liquid or solid object tall into the unit, remove the
batteries and disconnect the ac power adaptor, and have the unit
checked by qualified personnel before operating It any further
© Keeping the tape heads in a clean condition is essentiai to the
proper operation of the recorder. For cleaning information, refer
to page 16.
With a clean head
With a dirty head
(The output level
fluctuates)
Frequency response
a Ratt See Sai
With’a clean head ||
: tab i
iran | wan a dirty hear
(Even hardly visible dust] "}
' layer of 1.5 u deteriorates mn
\
nh
Output jevel (38)
1
boa agi.
I"
'
Debus sh
1k
Frequency (H2)
@The Record Button cannot be depressed in the following
cases. Never depress the button forcibly
No cassette in the Cassette Compartment.
«The cassette inserted has had the tabs removed.
+The Forward, Fast Forward or Rewind Button has been de-
pressed.
@ if you have any question or problem concerning your set that
is not covered in this manual, please consult the nearest Sony
Service Station authorized to service tape recorders (in the USA),
the nearest Sony of Canada Factory Service Station (in Canada)
or the nearest Sony dealer (in other countries).
Ba

Sony TC-D5 Specifications

General

Track System	4-track, 2-channel stereo
Tape Speed	4.8 cm/s
Type	Cassette Deck
Wow and Flutter	0.08% WRMS
Frequency Response	40Hz to 15kHz
Signal to Noise Ratio	58 dB (Dolby B on)
Input	Line, Mic
Output	Line, Headphones
Power Supply	6 V DC (4 x AA batteries or AC adapter)
