Specifications
8 (GB)
Video signal
Color system NTSC, PAL, SECAM, NTSC4.43
Resolution 450 TV lines
Aperture correction
–4.0 dB to +6.0 dB (at 3.0 MHz)
Frequency response
6.0 MHz (–3.0 dB)
Synchronization AFC time constant 1.0 msec.
Picture performance
Normal scan 6% over scan of CRT effective
screen area
Underscan 3% underscan of CRT effective
screen area
Linearity Less than 2.0%
Convergence Central area: 0.43 mm (typical)
Peripheral area: 0.53 mm (typical)
Raster size stability
H: 1.0%, V: 1.5%
High voltage regulation
3.0%
Color temperature D65
Inputs
COMPONENT SDI IN: BNC connector
Serial digital (270M bits/s)
SMPTE 259M/CCIR 656-III
Y/C IN: 4-pin mini DIN connector
See the pin assignment on page 9 (GB).
VIDEO IN: BNC connector
1 Vp-p, ± 6 dB, sync negative
R/R-Y, G/Y, B/B-Y: BNC connector
R, G, B channels: 0.7 Vp-p,
± 6 dB
Sync on green: 0.3 Vp-p,
negative, 75 ohms terminated
R-Y, Y, B-Y channels: 0.7 Vp-p,
±6 dB (Standard color bar signal
of 100% chrominance)
EXT SYNC IN: BNC connector
Composite sync 4 Vp-p, ±6 dB,
negative
Loop-through outputs
COMPONENT SDI OUT: BNC connector
Active through output
Serial digital (270M bits/s)
SMPTE 259M/CCIR 656-III
Y/C OUT: 4-pin mini DIN connector (75 ohms
automatic termination)
VIDEO OUT: BNC connector (75 ohms automatic
termination)
EXT SYNC OUT: BNC connector (75 ohms automatic
termination)
REMOTE input
REMOTE: 8-pin mini DIN connector
See the pin assignment on page 9 (GB).
General
Power consumption
BVM-8045QD:
48W max. at AC operation
44W at DC operation
BVM-9045D:
45W at AC operation
42W at DC operation
Power requirements
BVM-8045QD:
120 V AC, 50/60Hz
12 V DC with the AC-550
AC Adaptor (not supplied), etc.
BVM-9045D
100 to 240 V AC, 50/60 Hz
12 V DC with the AC-550CE
AC Adaptor (not supplied), etc.
Peak inrush current (BVM-9045D)
Hot switching inrush current, measured in
accordance with European
standard EN55103-1: 70A
(230V)
Operating conditions
Temperature 0 to +35°C (32 to 95°F)
Humidity 0 to 90% (no condensation)
Pressure 700 to 1060 hPa
Specifications
