Sony TRINITRON BVM-8045QD User Manual

2
3
4
5
AB C D E F G H
1
10-2210-22
S MIC Chassis
B MOUNT (2/3) VOLTAGES
IC
PAL SECAM NTSC
IC106 1 0 0 0
2 0.2 0.2 0.2
3 12VB 12VB 12VB
4 1.8 1.8 1.8
5 12VB 12VB 12VB
612 12 12
7NC NC NC
8 GND GND GND
9 10.2 10.2 10.2
10 1.2 1.2 1.2
11 12 12 12
12 1.7 1.7 1.7
13 12VB 12VB 12VB
14 9.8 9.8 9.8
15 GND GND GND
16 12VB 12VB 12VB
IC108 1 0.3 0.3 0.5
2 GND GND GND
3 GND GND GND
4 0.4 0.4 0.4
5 0.4 0.4 0.4
6 GND GND GND
7 GND GND GND
8 GND GND GND
9 8.2 8.2 8.2
10 5.7 5.7 5.7
11 9.8 9.8 0.5
12 0.5 0.5 0.5
13 0.3 0.3 0.3
14 0.2 0.2 0.5
15 0.2 0.2 0.5
16 12VB 12VB 12VB
IC109 1 GND GND GND
2 11.2 11.2 0
3 11.6 11.6 0
4 11.9 11.9 0
5 11.3 11.3 0
6 0.6 10.6 0
7 GND GND GND
8 GND GND GND
9 0.6 0.6 0.6
10 0.5 0.5 0.5
11 0.4 0.4 0.4
12 10.5 10.5 10.5
13 8.8 8.8 8.8
14 12VB 12VB 12VB
IC118 1 5.4 5.4 5.4
2 2.8 2.8 0
3 5.4 5.4 5.4
40 0 0
5 5.4 5.4 5.4
6 12VB 12VB 12VB
7 5.7 5.7 5.7
8 GND GND GND
IC120 1 5.1 5.1 5.1
2 5.1 5.1 5.1
3 5.1 5.1 5.1
4 5.1 5.1 5.1
5 0.4 0.4 0.4
6 8.3 8.3 8.3
7 GND GND GND
8 12VB 2VB 2VB
912 12 12
10 4.8 4.8 4.8
11 5.1 5.1 5.1
12 0.5 0.5 0.5
13 0.4 0.4 0.4
14 12VB 12VB 12VB
PAL SECAM NTSC
IC121 1 5.1 5.1 5.1
2 5.1 5.1 5.1
3 5.1 5.1 5.1
4 5.1 5.1 5.1
5 0 5.1 5.1
6 GND GND GND
7 GND GND GND
8 GND GND GND
92 2 2
10 2 2 2
11 2 2 2
12 5.1 5.1 5.1
13 4.8 4.8 4.8
14 5.1 5.1 5.1
15 0 0 5.1
16 12VB 12VB 12VB
IC 122 1 4.8 4.8 4.8
2 4.8 4.8 4.8
3 4.8 4.8 4.8
4 GND GND GND
5 5.1 5.1 5.1
6 5.1 5.1 5.1
7 5.1 5.1 5.1
8 12VB 12VB 12VB
IC123 1 0.6 10.7 0
2 2.5 2.5 2.5
3 1.7 1.7 1.7
4 GND GND GND
5 5.1 5.1 5.1
6 5.1 5.1 5.1
7 5.1 5.1 5.1
8 12VB 12VB 12VB
IC128 1 3 3 3
23 3 3
3 2.9 2.9 2.9
4 GND GND GND
5 5.3 5.3 4.6
65 5 5
7 10.4 9.0 0
8 12VB 12VB 12VB
TRANSISTOR
Q136 1 12VB 12VB 12VB
2 5.7 5.7 5.7
3 5.1 5.1 5.1
4 10.5 10.5 10.5
5 5.7 5.7 5.7
6 5.1 5.1 5.1
Q137 1 12VB 12VB 12VB
2 5.7 5.7 5.7
3 5.1 5.1 5.1
4 10.5 10.5 10.5
5 5.7 5.7 5.7
6 5.1 5.1 5.1
Q138 1 12VB 12VB 12VB
2 5.7 5.7 5.7
3 5.1 5.1 5.1
4 10.5 10.5 10.5
5 5.7 5.7 5.7
6 5.1 5.1 5.1
Q132 B 6 6 6
C 1.7 1.7 1.7
E 2.3 2.3 2.3
. All voltages are in V (volt).
. NC: No connection.
B (2/3) BOARD WAVEFORMS
SECAM 60 mV p-p (H)
NTSC3.58 0.35 V p-p (H)
NTSC4.43 0.35 V p-p (H)
PAL 0.35 V p-p (H) SECAM 60 mV p-p (H)PAL 0.25 V p-p (H)
NTSC3.59 0.36 V p-p (H)
NTSC4.43 0.36 V p-p (H)
PAL 0.38 V p-p (H)
SECAM 0.38 V p-p (H) 12 V p-p (H) PAL 3.6 V p-p (H)NTSC3.58 0.28 V p-p (H)
4 V p-p (H) 12 V p-p (H) 12 V p-p (H)PAL 1.9 V p-p (H)
12 V p-p (H)
PAL 12.6 V p-p (H)
SECAM 12.6 V p-p (H)
NTSC3.58 12.6 V p-p (H)
NTSC4.43 12.6 V p-p (H)
12 V p-p (H) SECAM 0.5 V p-p (H) SECAM 0.5 V p-p (H)PAL 0.92 V p-p (H)
NTSC3.58 0.8 V p-p (H)
NTSC4.47 0.8 V p-p (H) 12 V p-p (H) 12 V p-p (H) 12 V p-p (H)
PAL 0.9 V p-p (H)
SECAM 0.9 V p-p (H)
SECAM 1 V p-p (H)
NTSC3.58 0.85 V p-p (H)
NTSC4.43 0.85 V p-p (H)
PAL 0.9 V p-p (H) SECAM 0.9 V p-p (H)PAL 0.85 V p-p (H)
PAL 1.3 V p-p (H)
SECAM 1.3 V p-p (H)
NTSC3.58 1 V p-p (H)
NTSC4.43 1 V p-p (H)
NTSC3.58 0.9 V p-p (H)
NTSC4.43 0.9 V p-p (H)
21
432
5
678
90
!- !=
!;
![ !] !\
!' !, !.
@/
@-
@-
@=
B (2/3) B (2/3)
