Sony Trinitron CPD-210EST9 User Manual (English)

Questions and Answers:

A
Amy JohnsonAug 18, 2025
Why is my Sony Monitor picture flickering, bouncing, oscillating, or scrambled?
- L
  Lisa RiosAug 18, 2025
  If your Sony Monitor's picture flickers, bounces, oscillates, or is scrambled, try the following: * Isolate and eliminate any potential sources of electric or magnetic fields such as other monitors, laser printers, electric fans, fluorescent lighting, or televisions. * Move the monitor away from power lines or place a magnetic shield near it. * Try plugging the monitor into a different AC outlet, preferably on a different circuit. * Try turning the monitor 90° to the left or right.
M
mezabrandonAug 20, 2025
What to do if there is no picture on my Sony Monitor?
- C
  Carol SchmidtAug 21, 2025
  If there is no picture on your Sony Monitor, ensure the power cord is properly connected and the power switch is in the “on” position. Also, check that the video signal cable is correctly connected and all plugs are firmly seated. Verify that the HD15 video input connector’s pins are not bent. If your computer is in power saving mode, press any key on the keyboard. Make sure the computer’s power is on and the graphic board is completely seated in the proper bus slot.
M
martinanthonyAug 23, 2025
How to fix OUT OF SCAN RANGE message on Sony Trinitron CPD-210EST9?
- S
  Shannon CantrellAug 23, 2025
  If the OUT OF SCAN RANGE message appears on your Sony Monitor, check that the video frequency range is within that specified for the monitor. If you replaced an old monitor with this monitor, reconnect the old monitor and adjust the frequency range to the following: Horizontal: 30 – 70 kHz Vertical: 48 – 120 Hz.
W
William PageAug 26, 2025
How to resolve a fuzzy picture on my Sony Trinitron CPD-210EST9?
- C
  Christina AguirreAug 26, 2025
  To resolve a fuzzy picture on your Sony Monitor, adjust the contrast and brightness. You can also degauss the monitor or decrease the moire cancellation effect.
B
bradleyrichardAug 28, 2025
Why is the color not uniform on my Sony Trinitron CPD-210EST9 Monitor?
- J
  Jeanette WallaceAug 28, 2025
  If the color is not uniform on your Sony Monitor, degauss the monitor. Placing equipment that generates a magnetic field, such as a speaker, near the monitor, or changing the direction the monitor faces, may cause color to lose uniformity.
M
Marc Mcintosh MDAug 30, 2025
What causes ghosting on my Sony Monitor picture?
- M
  Mary MitchellAug 30, 2025
  If your Sony Monitor picture is ghosting, eliminate the use of video cable extensions and/or video switch boxes. Also, ensure that all plugs are firmly seated in their sockets.
T
Tyler MillerSep 2, 2025
How do I fix a wavy pattern on my Sony Trinitron CPD-210EST9 Monitor (moire)?
- L
  Lynn WareSep 2, 2025
  To fix a wavy or elliptical pattern (moire) visible on your Sony Monitor, cancel the moire.
T
Traci WagnerSep 4, 2025
How to center the picture on my Sony Trinitron CPD-210EST9 Monitor?
- K
  Katelyn AndrewsSep 4, 2025
  To center the picture or adjust its size on your Sony Monitor, adjust the size or centering settings.
M
Michelle LunaSep 7, 2025
How do I correct curved edges on my Sony Trinitron CPD-210EST9 Monitor image?
- A
  Amy RichardSep 7, 2025
  To correct curved edges on the image of your Sony Monitor, adjust the shape of the picture.
D
David PenningtonSep 9, 2025
Why does white not look white on my Sony Trinitron CPD-210EST9 Monitor?

Sony Trinitron CPD-210EST9 Specifications

General

Brand	Sony
Model	Trinitron CPD-210EST9
Category	Monitor
Language	English

Summary

Owner's Record

Safety and Warnings

General Safety Precautions

Warnings about fire, shock hazards, and cabinet opening.

Regulatory Compliance

Compliance information for FCC, EN 55022, and general declarations.

Environmental and Health Information

MPR II and TCO'99 Standards

Product compliance with MPR II and TCO'99 environmental and ergonomic standards.

Precautions

Power Connection and Static Discharge

Guidelines for using the correct power cord and handling static discharge.

Installation and Placement

Recommendations for optimal and safe monitor placement.

Maintenance and Cleaning

Instructions for cleaning the screen and unit.

Transportation Advice

Guidance for safe transport of the monitor.

Identifying Parts and Controls

Front Panel Overview

Description of buttons and indicators on the monitor's front panel.

Rear Panel Connections

Description of video input and power connectors on the rear.

Monitor Setup Procedure

Connecting to Your Computer

Instructions for connecting the monitor to IBM PC/AT or Macintosh computers.

Connecting the Power Cord

Instructions for connecting the monitor to a power outlet.

Powering On the System

Sequence for turning on the monitor and computer.

Troubleshooting Display Issues

No Picture or Signal Errors

Guidance for resolving no picture, OUT OF SCAN RANGE, and NO INPUT SIGNAL messages.

Windows Configuration

Monitor Information Disk Installation

Procedure for installing the Windows Monitor Information Disk for optimal performance.

Resolution and Color Adjustment

How to adjust monitor resolution and color depth settings.

Menu Language Customization

Selecting On-Screen Menu Language

Steps to choose the on-screen menu language from available options.

Customizing Your Monitor

Navigating the On-Screen Menu

Instructions on how to use the MENU and navigation buttons.

Picture Adjustment Overview

Overview of adjustable picture settings like contrast, size, shape, and color.

System Settings Overview

Overview of language, degauss, and reset functions.

Using Menu Controls

Navigating Menu Items

Steps to select and adjust menu items using buttons.

Adjusting Contrast and Brightness

Detailed steps for adjusting contrast and brightness levels.

Resetting Monitor Adjustments

Instructions for resetting current or factory preset adjustments.

Adjusting Picture Geometry

Horizontal Size and Centering

How to adjust the horizontal dimensions and position of the picture.

Vertical Size and Centering

How to adjust the vertical dimensions and position of the picture.

Picture Side Curvature Adjustment

Adjusting the curvature of the picture's sides (PIN/PIN BALANCE).

Picture Side Angle Adjustment

Adjusting the angle of the picture's sides (KEY/KEY BALANCE).

Adjusting Picture Properties

Picture Rotation Adjustment

How to rotate the picture display.

Picture Zoom Adjustment

How to enlarge or reduce the picture size.

Picture Color Temperature Tuning

Adjusting color temperature and fine-tuning RGB levels.

Advanced Settings and Reset

Degauss and Moire Cancellation

Manually degaussing the screen and cancelling moire patterns.

Resetting Monitor Settings

Procedures for resetting current or factory preset adjustments.

Technical Features Overview

Preset and User Modes

How the monitor matches signals to preset modes or stores user adjustments.

Power Saving Functionality

Details on the monitor's power saving modes and consumption.

Troubleshooting Guide

Thin Lines on Screen Explanation

Explanation of normal thin lines caused by damper wires in Trinitron displays.

On-Screen Message Interpretation

Interpreting messages like OUT OF SCAN RANGE and NO INPUT SIGNAL.

Trouble Symptoms and Remedies

No Picture and Signal Issues

Troubleshooting steps for no picture, no signal, and out of range messages.

Windows and Macintosh System Issues

Troubleshooting for Windows 95/98 and Macintosh systems.

Picture Quality Problems

Resolving issues like flickering, fuzzy pictures, and curved edges.

Advanced Troubleshooting

Picture Distortion and Color Problems

Troubleshooting ghosting, centering, curvature, moire, and color uniformity.

Displaying Monitor Information

How to access and display model name, serial number, and date of manufacture.

Self-Diagnosis Function

Performing Self-Diagnosis

Steps to run the self-diagnosis function for monitor or computer problems.

Product Specifications

CRT and Display Specifications

Details on CRT type, viewable size, resolution, and deflection frequency.

Power, Dimensions, and Mass

Specifications for AC input, power consumption, dimensions, and mass.

Appendix

Preset Mode Timing Table

Table listing resolution, horizontal/vertical frequencies, and graphics modes.

TCO'99 Eco-document

About TCO'99 Environmental Approval

Explanation of TCO'99 approval and its environmental considerations.

Environmental Requirements Summary

Flame Retardants and PCBs

Information on flame retardants, PCBs, and bio-accumulative risks.

Heavy Metal Restrictions

Requirements regarding Cadmium, Mercury, and Lead.

CFCs (Freons) Restrictions

Information on the prohibition of CFCs (freons) in manufacturing.
