— 49 —
KV-20WS1
The components identified by
shading and marked are critical
for safety.
Replace only with the part number
specified.
Les composants identifies par
une trame et une marque sont
critiques pour la securite.
Ne les remplacer que par une piece
portant le numero specifie.
REF.NO. PART NO. DESCRIPTION REMARKREF.NO. PART NO. DESCRIPTION REMARK
ELECTRICAL PARTS LIST
SECTION 7
When indicating parts by reference
number, please include the board
name.
CAPACITORS COILS
The components identified by
shading and marked are critical
for safety.
Replace only with the part number
specified.
Les composants identifies par
une trame et une marque sont
critiques pour la securite.
Ne les remplacer que par une piece
portant le numero specifie.
MF : mF , PF : mmF MMH : mH , µH : mH
A
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be anticipated
when ordering these items.
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
RESISTORS
• All resistors are in ohms
• F : nonflammable
REF.NO. PART NO. DESCRIPTION REMARKREF.NO. PART NO. DESCRIPTION REMARK
*A-1632-654-A A BOARD, COMPLETE (KV-20WS1A)
*****************
*A-1632-655-A A BOARD, COMPLETE (KV-20WS1B)
*****************
*A-1632-653-A A BOARD, COMPLETE (KV-20WS1D)
*A-1632-700-A A BOARD, COMPLETE (Greek Text)
*****************
*A-1632-652-A A BOARD, COMPLETE (KV-20WS1E)
*****************
*A-1632-658-A A BOARD, COMPLETE (KV-20WS1K)
*****************
*A-1632-657-A A BOARD, COMPLETE (KV-20WS1R)
*****************
*A-1632-656-A A BOARD, COMPLETE (KV-20WS1U)
*****************
< CAPACITOR >
C001 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C002 1-126-968-11 ELECT 100MF 20% 50V
C003 1-164-492-11 CERAMIC CHIP 0.15MF 10% 16V
C004 1-163-034-00 CERAMIC CHIP 0.033MF 50V
C005 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C006 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C007 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C008 1-126-965-11 ELECT 22MF 20% 50V
C009 1-126-961-11 ELECT 2.2MF 20% 50V
C010 1-163-033-91 CERAMIC CHIP 0.022MF 50V
C011 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C012 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C013 1-163-078-11 CERAMIC CHIP 0.033MF 10% 25V
C014 1-164-346-11 CERAMIC CHIP 1MF 16V
C015 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C016 1-164-222-11 CERAMIC CHIP 0.22MF 25V
C017 1-162-638-11 CERAMIC CHIP 1MF 16V
C018 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C019 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C020 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C021 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C022 1-126-960-11 ELECT 1MF 20% 50V
C024 1-126-965-11 ELECT 22MF 20% 50V
C025 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C026 1-126-965-11 ELECT 22MF 20% 50V
C027 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C028 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C029 1-163-077-00 CERAMIC CHIP 0.1MF 50V
C030 1-163-077-00 CERAMIC CHIP 0.1MF 50V
C031 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C034 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C035 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C036 1-126-965-11 ELECT 22MF 20% 50V
C037 1-164-346-11 CERAMIC CHIP 1MF 16V
C038 1-164-346-11 CERAMIC CHIP 1MF 16V
C039 1-163-205-00 CERAMIC CHIP 0.001MF 10% 50V
C040 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C041 1-126-965-11 ELECT 22MF 20% 50V
C042 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C044 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C045 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C046 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C099 1-165-320-11 CERAMIC CHIP 0.47MF 10% 16V
C121 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C122 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
C123 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C124 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
C131 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C135 1-126-934-11 ELECT 220MF 20% 16V
C136 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C162 1-126-967-11 ELECT 47MF 20% 16V
C201 1-126-965-11 ELECT 22MF 20% 50V
C202 1-126-941-11 ELECT 470MF 20% 25V
C205 1-126-963-11 ELECT 4.7MF 20% 50V
C206 1-126-933-11 ELECT 100MF 20% 16V
C207 1-126-933-11 ELECT 100MF 20% 16V
C208 1-126-963-11 ELECT 4.7MF 20% 50V
C210 1-163-033-91 CERAMIC CHIP 0.022MF 50V
C211 1-126-965-11 ELECT 22MF 20% 50V
C213 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C214 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C215 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
(KV-20WS1B)
C216 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C217 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C218 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C219 1-126-964-11 ELECT 10MF 20% 50V
C220 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C221 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
(KV-20WS1B)
C222 1-126-934-11 ELECT 220MF 20% 16V
C223 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C224 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C225 1-126-964-11 ELECT 10MF 20% 50V
C226 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
To Next Page
