KV-20WS1
— 50 —
The components identified by
shading and marked are critical
for safety.
Replace only with the part number
specified.
Les composants identifies par
une trame et une marque sont
critiques pour la securite.
Ne les remplacer que par une piece
portant le numero specifie.
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
A
C227 1-163-084-00 CERAMIC CHIP 1.5PF 0.25PF 50V
C228 1-163-084-00 CERAMIC CHIP 1.5PF 0.25PF 50V
C229 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C230 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C231 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C232 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C233 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C234 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C235 1-126-964-11 ELECT 10MF 20% 50V
C236 1-126-964-11 ELECT 10MF 20% 50V
C240 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C242 1-164-346-11 CERAMIC CHIP 1MF 16V
C243 1-164-346-11 CERAMIC CHIP 1MF 16V
C244 1-164-346-11 CERAMIC CHIP 1MF 16V
C245 1-164-346-11 CERAMIC CHIP 1MF 16V
C246 1-126-965-11 ELECT 22MF 20% 50V
C247 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C300 1-126-942-61 ELECT 1000MF 20% 25V
C301 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C302 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C303 1-126-965-11 ELECT 22MF 20% 50V
C304 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C305 1-124-257-00 ELECT 2.2MF 20% 50V
C306 1-136-164-00 FILM 0.082MF 5% 50V
C307 1-163-077-00 CERAMIC CHIP 0.1MF 10% 25V
C308 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C309 1-126-163-11 ELECT 4.7MF 20% 50V
C310 1-163-077-00 CERAMIC CHIP 0.1MF 10% 25V
C311 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C312 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C313 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C314 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C315 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C316 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C317 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C319 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C320 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C321 1-126-963-11 ELECT 4.7MF 20% 50V
C322 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
C323 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C324 1-163-119-00 CERAMIC CHIP 120PF 5% 50V
C325 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C326 1-164-489-91 CERAMIC CHIP 0.22MF 16V
C327 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C328 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C329 1-163-016-00 CERAMIC CHIP 0.0039MF 10% 50V
C330 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C331 1-104-665-11 ELECT 100MF 20% 25V
C332 1-126-965-11 ELECT 22MF 20% 50V
C333 1-107-715-11 ELECT 22MF 20% 16V
C341 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C345 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C347 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C353 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C355 1-163-059-91 CERAMIC CHIP 0.01MF 10% 50V
C359 1-126-965-11 ELECT 22MF 20% 50V
C360 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C401 1-126-967-11 ELECT 47MF 20% 16V
C402 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C403 1-164-346-11 CERAMIC CHIP 1MF 16V
C404 1-164-346-11 CERAMIC CHIP 1MF 16V
C405 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C406 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C408 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C409 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C410 1-126-967-11 ELECT 47MF 20% 16V
C411 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C412 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C413 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C414 1-126-967-11 ELECT 47MF 20% 16V
C415 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C416 1-126-965-11 ELECT 22MF 20% 50V
C417 1-126-965-11 ELECT 22MF 20% 50V
C418 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C419 1-164-346-11 CERAMIC CHIP 1MF 16V
C420 1-164-346-11 CERAMIC CHIP 1MF 16V
C421 1-164-337-11 CERAMIC CHIP 2.2MF 16V
C422 1-164-337-11 CERAMIC CHIP 2.2MF 16V
C423 1-164-337-11 CERAMIC CHIP 2.2MF 16V
C424 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C425 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C500 1-137-374-11 FILM 0.047MF 5% 50V
C501 1-126-963-11 ELECT 4.7MF 20% 50V
C502 1-163-077-00 CERAMIC CHIP 0.1MF 50V
C503 1-126-952-11 ELECT 1000MF 20% 35V
C504 1-126-968-11 ELECT 100MF 20% 50V
C505 1-126-941-11 ELECT 470MF 20% 25V
C506 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C507 1-126-965-11 ELECT 22MF 20% 50V
C508 1-130-785-11 MYLAR 0.47MF 10% 100V
C510 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C511 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C601 1-136-516-12 FILM 0.1MF 20% 300V
C602 1-136-516-12 FILM 0.1MF 20% 300V
C603 1-117-700-61 CERAMIC 0.0022MF 20% 250V
C604 1-117-700-11 CERAMIC 0.0022MF 20% 250V
C605 1-162-964-91 CERAMIC 0.0047MF 250V
C606 1-162 964-91 CERAMIC 0.0047MF 250V
C610 1-104-665-11 ELECT 100MF 20% 25V
C611 1-136-538-11 FILM 0.001MF 3% 2KV
C612 1-107-929-11 ELECT 10MF 20% 100V
C613 1-162-318-11 CERAMIC 0.001MF 10% 500V
C614 1-104-666-11 ELECT 220MF 20% 25V
C615 1-124-347-00 ELECT 100MF 20% 160V
C616 1-162-116-00 CERAMIC 680PF 10% 2KV
C617 1-107-929-11 ELECT 10MF 20% 100V
C618 1-102-228-00 CERAMIC 470PF 10% 500V
C619 1-126-942-61 ELECT 1000MF 20% 25V
C621 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C622 1-126-965-11 ELECT 22MF 20% 50V
C623 1-111-055-91 ELECT 56MF 20% 25V
C624 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C625 1-126-967-11 ELECT 47MF 20% 50V
C626 1-102-228-00 CERAMIC 470PF 10% 500V
C627 1-111-097-11 ELECT 0.0022F 20% 35V
C628 1-126-964-11 ELECT 10MF 20% 50V
C629 1-126-933-11 ELECT 100MF 20% 16V
C630 1-113-473-11 ELECT(BLOCK) 180MF 20% 400V
C631 1-124-910-11 ELECT 47MF 20% 50V
C632 1-106-228-00 MYLAR 0.22MF 10% 100V
