REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
— 102 —
HV
COMPLETE PARTS LISTING
HV
* A-1372-505-A HV BOARD, COMPLETE
(KV-32V40 only)
* A-1372-509-A HV BOARD, COMPLETE
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
* A-1372-523-A HV BOARD, COMPLETE
(KV-35S40/35S45/37SL45 only)
CAPACITOR
C2068 1-104-665-11 ELECT 100MF 20% 25V
C2070 1-165-319-11 CERAMIC CHIP 0.1MF 50V
C2231 1-163-031-11 CERAMIC CHIP 0.01MF 50V
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
C2232 1-136-161-00 FILM 0.047MF 5% 50V
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
C2233 1-136-161-00 FILM 0.047MF 5% 50V
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
(KV-32V40 only)
C2234 1-126-960-11 ELECT 1MF 20% 50V
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
(KV-32V40 only)
C2235 1-126-960-11 ELECT 1MF 20% 50V
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
(KV-32V40 only)
CONNECTOR
CN2002* 1-564-518-11 PLUG, CONNECTOR 3P
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
DIODE
D2006 1-810-039-11 LED UNIT
D2231 8-719-110-17 DIODE RD10ESB2
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
D2232 8-719-110-17 DIODE RD10ESB2
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
D2233 8-719-110-17 DIODE RD10ESB2
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
D2236 8-719-110-17 DIODE RD10ESB2
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
(KV-32V40 only)
IC
IC2003 8-742-014-11 HYB IC SBX1981-51
JACK
J2231 1-691-110-11 JACK, PIN 3P
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
(KV-32V40 only)
J2232 1-694-063-11 TERMINAL, S
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
RESISTOR
R2009 1-216-033-00 RES, CHIP 220 5% 1/10W
R2010 1-216-033-00 RES, CHIP 220 5% 1/10W
R2059 1-216-047-91 RES, CHIP 820 5% 1/10W
(KV-35S40/35S45/37SL45 only)
R2060 1-216-049-91 RES, CHIP 1K 5% 1/10W
(KV-32V40 only)
(KV-35S40/35S45/37SL45 only)
R2061 1-216-055-00 RES, CHIP 1.8K 5% 1/10W
(KV-32V40 only)
(KV-35S40/35S45/37SL45 only)
R2062 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
(KV-32V40 only)
(KV-35S40/35S45/37SL45 only)
R2063 1-216-073-00 RES, CHIP 10K 5% 1/10W
(KV-32V40 only)
(KV-35S40/35S45/37SL45 only)
R2231 1-216-022-00 RES, CHIP 75 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R2232 1-216-022-00 RES, CHIP 75 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R2233 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R2235 1-216-022-00 RES, CHIP 75 5% 1/10W
(KV-32V40 only)
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R2236 1-216-113-00 RES, CHIP 470K 5% 1/10W
KV-32V40 only)
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R2237 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
KV-32V40 only)
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R2238 1-216-113-00 RES, CHIP 470K 5% 1/10W
KV-32V40 only)
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R2239 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
(KV-32V40 only)
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
SWITCH
