– 2 –
Note
Power requirements 110-240 V AC, 50/60 Hz
Power consumption (W) Indicated on the rear of the TV
Television system B/G, I, D/K, M
Color system PAL, PAL 60, SECAM, NTSC4.43, NTSC3.58
Channel coverage
B/G VHF: E2 to E12 / UHF: E21 to E69 / CATV: S01 to S03, S1 to S41
I UHF: B21 to B68 / CATV: S01 to S03, S1 to S41
D/K VHF: C1 to C12, R1 to R12 / UHF: C13 to C57, R21 to R60
CATV: Z1 to Z39, S01 to S03, S1 to S41
M VHF: A2 to A13 / UHF: A14 to A79 /
CATV: A-8 to A-2, A to W+4, W+6 to W+84
Antenna 75-ohm external terminal
Audio output (speaker) 6W + 6W
Number of terminal
Video Input: 3 Output:1 Phono jacks; 1 Vp-p, 75 ohms
Audio Input: 3 Output: 1 Phono jacks; 500 mVrms
S Video Input: 1 Y : 1 Vp-p, 75 ohms,
unbalanced, sync negative
C : 0.286 Vp-p, 75 ohms
Headphone Output: 1 Minijack
Picture tube Super Trinitron Super Trinitron Plus
(25 in.) (29 in.)
Tube size (cm) 64 72 Measured diagonally
Screen size (cm) 60 68 Measured diagonally
Dimension (w/h/d, mm) 712 × 521 × 520 780 × 577 × 542
Mass (kg) 33 43
Accessory (optional) TV stand (SU-25H) TV stand (SU-29H)
SPECIFICATIONS
CAUTION
SHORT CIRCUIT THE ANODE OF THE PICTURE TUBE
AND THE ANODE CAP TO THE METAL CHASSIS, CRT
SHIELD, OR CARBON PAINTED ON THE CRT, AFTER
REMOVING THE ANODE.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARK !
ON THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND
IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
KV-J25MF8J KV-J29MF8J
Design and specifications are subject to change without notice.
