Sony TRINITRON KV-PG14P70 - A Board Voltage List (Part 2)

– 40 –
KV-PG14M40/PG14M72/L/N
KV-PG14P42/G/L/N/PG14P70
RM-952
A(2/2) BOARD VOLTAGE LIST
Ref Pin No Voltage[v]
Ref Pin No Voltage[v] Ref Pin No Voltage[v]
IC601 1 0.9
2 0.2
3 (45.5) [0.4]
4 (8.7) [0.4]
5 (0.2) [0]
IC602 1 0
2 121.9
3 134
IC604 I 13.4
G 8.9
O0
IC850 1 (*) [2.2]
2 0.8
3 1.0
40
5 2.7
6 (*) [2.2]
7 5.9
8 8.9
IC851 1 (2.2) [2.7]
2 3.2
3 3.2
40
5 (2.5) [2.8]
6 (2.5) [2.8]
7 (3.9) [3.7]
8 8.9
PH600 1 133.4
2 (121.7) [*]
3 (134.4) [8.7]
4 (134.4) [1.4]
Q002 B (5.0) [0]
C (0) [4.9]
E0
Q003 B (0.4) [0.1]
C 5.0
E0
Q004 B (0.2) [0.1]
C 5.0
E (0.1) [0.2]
Q100 B 3.6 [7.4]
C 8.8
E (4.2) [8]
Q103 B 0
C 3.2
E0
Q104 B 0
C0
E (0.4) [3.2]
Q105 B (0.4) [0]
C (9.3) [0]
E (0) [0.6]
Q106 B 0
C 3.9
E 0.6
Q201 B (0.4) [4.7]
C 8.9
E 5.3
Q204 B 16.5
C 16.5
E 15.8
Q205 B (4.8) [0.2]
C (0) [0.2]
E (0) [4.8]
Q300 B (3.0) [3.6]
C0
E 8.9
Q301 B (3.0) [3.6]
C0
E (2.3) [3.9]
Q302 B (3.0) [3.9]
C0
E 8.9
Q303 B (2.3) [3.7]
C (7.7) [6.1]
E (2.9) [4.2]
Q304 B (2.9) [4.2]
C (2.3) [3.7]
E 8.9
Q305 B (3.0) [4.0]
C (2.3) [3.5]
E (2.3) [3.6]
Q306 B 8.9
C 8.9
E (2.9) [4.6]
Q307 B 8.9
C (3.2) [9.0]
E (2.9) [4.7]
Q308 B 0
C (0.3) [8.8]
E (0.2) [0]
Q309 B (1.7) [3.8]
C (4.5) [9.0]
E (2.9) [4.7]
Q310 B 0
C 8.9
E0
Q311 B 8.9
C 8.9
E (2.9) [4.7]
Q312 B 0
C0
E 3.9
Q313 B 0
C 8.9
E0
Q314 B 0
C 0.6
E0
Q315 B 2.6
C 8.9
E0
Q318 B 2.1
C (0.4) [5.4]
E 2.7
Q320 B 0
C 3.3
E0
Q400 B 13.3
C -0.3
E 13.4
Q401 B 0
C0
E (-0.5) [-0.1]
Q402 B 0
C 0.4
E (-0.5) [-0.2]
Q403 B 0.4
C0
E (0.4) [0.6]
Q404 B 5.2
C0
E 4.5
Q405 B 3.2
C0
E 2.5
Q406 B 1.8
C 4.2
E 2.5
Q407 B (0.5) [3.5]
C 8.9
E 4.2
Q801 B 0.2
C0
E0
Q802 B 5.0
C (8) [9]
E0
Q850 B 5.8
C 8.9
E 5.9
Q851 B (5.6) [6.0]
C0
E 5.9
