– 48 –
KV-PG14M40/PG14M72/L/N
KV-PG14P42/G/L/N/PG14P70
RM-952
1 X-4039-346-1 BEZNET ASSY 24
(KV-PG14M40/PG14P42/PG14P70)
X-4039-575-1 BEZNET ASSY (KV-PG14M72)
X-4039-591-1 BEZNET ASSY (KV-PG14M72(L))
X-4039-614-1 BEZNET ASSY (KV-PG14M72(N))
X-4039-449-1 BEZNET ASSY (KV-PG14P42(G))
X-4039-452-1 BEZNET ASSY (KV-PG14P42(L))
X-4039-479-1 BEZNET ASSY (KV-PG14P42(N))
2 4-081-868-01 BUTTON POWER
3 X-4039-345-1 DOOR ASSY, CONTROL (KV-PG14M40)
X-4039-555-1 DOOR ASSY, CONTROL (KV-PG14M72(L))
X-4039-613-1 DOOR ASSY, CONTROL (KV-PG14M72(N))
X-4039-480-1 DOOR ASSY, CONTROL (KV-PG14M72)
X-4039-713-1 DOOR ASSY, CONTROL (KV-PG14P42)
X-4039-715-1 DOOR ASSY, CONTROL (KV-PG14P42(G))
X-4039-714-1 DOOR ASSY, CONTROL (KV-PG14P42(L))
X-4039-716-1 DOOR ASSY, CONTROL (KV-PG14P42(N))
X-4039-301-1 DOOR ASSY, CONTROL (KV-PG14P70)
4 ! 8-735-570-05 PICTURE TUBE (A34LRG70X)
5 1-452-030-00 MAGNET DISK
6 4-082-275-01 COVER REAR (p 8 SCREWS)
7 * 3-704-372-11 HOLDER HV CABLE
8 4-081-577-01 SPACER (S) DY
(KV-PG14M40/PG14M72/
PG14M72/L/N/PG14P70)
4-064-818-01 SPACER DY (KV-PG14P42/PG14P42/L/G/N)
9 4-077-228-02 PIECE TLH CONVERGENCE
10 ! 8-451-401-11 DEFLECTION YOKE (Y14RSA-S)
11 1-900-212-58 LEAD ASSY FOCUS
12 * A-1332-226-A C BOARD MOUNTED
(KV-PG14M40/PG14M72/
PG14M72/L/N/PG14P70)
* A-1332-249-A C BOARD MOUNTED
(KV-PG14P42/ PG14P42/L/G/N)
13 4-365-808-01 SCREW(5) TAPPING
(KV-PG14M40/PG14M72/
PG14M72/L/N/PG14P70)
4-365-808-41 SCREW(5) TAPPING
(KV-PG14P42/ PG14P42/L/G/N)
REF. NO. PART NO. DESCRIPTION REMARK
14 4-078-765-01 SPRING EXTENSION
(KV-PG14M40/PG14M72/PG14M72/L/N/PG14P70)
4-078-765-11 SPRING EXTENSION
(KV-PG14P42/ PG14P42/L/G/N)
15 ! 1-419-185-11 COIL, DEGAUSSING
(KV-PG14M40/PG14M72/PG14M72/L/N/PG14P70)
! 1-419-185-31 COIL, DEGAUSSING
(KV-PG14P42/PG14P42/L/G/N)
16 1-544-965-11 SPEAKER (9 X 5CM)
17 4-051-736-42 PIECE A (90)CONV, CORRECT
18 * A-1299-645-A A BOARD COMPLETE (KV-PG14M40)
* A-1299-637-A A BOARD COMPLETE
(KV-PG14M72/PG14M72/L/N)
* A-1299-632-A A BOARD COMPLETE
(KV-PG14P42/PG14P42/L/G/N)
* A-1299-614-A A BOARD COMPLETE (KV-PG14P70)
19 ! 1-453-309-21 TRANSFORMER ASSY FLYBACK
(NX-4450//M3A4)
20 8-598-591-00 TUNER BT-AG402
21 ! 4-022-115-12 HOLDER AC CORD
(KV-PG14M40/PG14M72/PG14M72/L/N/PG14P70)
! 4-022-115-31 HOLDER AC CORD
(KV-PG14P42/PG14P42/L/G/N)
22 4-059-710-01 BRACKET, TERMINAL BOARD
(KV-PG14M40/PG14M72/PG14M72/L/N/PG14P70)
4-059-716-01 BRACKET TERMINAL BOARD
(KV-PG14P42/PG14P42/L/G/N)
23 ! 1-574-062-52 CORD POWER (WITH CONNECTOR)
(KV-PG14M40)
! 1-574-023-41 CORD POWER (WITH CONNECTOR)
(KV-PG14P42/PG14P42/L/N/G)
! 1-574-062-22 CORD POWER (WITH CONNECTOR)
(KV-PG14P70)
! 1-823-477-11 CORD, AC POWER (WITH CONNECTOR)
(KV-PG14M72/PG14M72/L/N)
24 * 4-081-867-01 BAR OPTICAL
25 * 4-072-857-02 CUSHION DGC
(KV-PG14M40/PG14M72/PG14M72/L/N/PG14P70)
* 4-072-857-12 CUSHION DGC (KV-PG14P42/PG14P42/L/G/N)
26 * A-1241-499-A F BOARD MOUNTED
(KV-PG14M72/PG14M72/L/N)
27 4-049-158-01 BRACKET F1 PC BOARD
(KV-PG14M72/PG14M72/L/N)
28 * A-1272-448-A A3 BOARD MOUNTED
(KV-PG14M72/PG14M72/L/N)
REF. NO. PART NO. DESCRIPTION REMARK
