KV-PG14M40/PG14M72/L/N
KV-PG14P42/G/L/N/PG14P70
RM-952
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
– 50 –
C105 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C106 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C107 1-126-935-11 ELECT 470UF 20.00% 16V
C108 1-126-767-11 ELECT 1000UF 20.00% 16V
C109 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C110 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
(KV-PG14M72/L/N)
C111 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C112 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
(KV-PG14M72/L/N)
C113 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
(KV-PG14M72/L/N)
C115 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C116 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C117 1-162-924-11 CERAMIC CHIP 56PF 5.00% 50V
C121 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C122 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
C124 1-130-493-00 MYLAR 0.068UF 5.00% 50V
C125 1-130-495-00 MYLAR 0.1UF 5.00% 50V
C126 1-130-493-00 MYLAR 0.068UF 5.00% 50V
C127 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C128 1-126-965-91 ELECT 22UF 20.00% 50V
C129 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C131 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V
C200 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
(KV-PG14M72/L/N)
C200 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
(KV-PG14M40/PG14P42/G/L/N/PG14P70)
C202 1-130-495-00 MYLAR 0.1UF 5.00% 50V
(KV-PG14M72/L/N)
C202 1-136-169-00 FILM 0.22UF 5.00% 50V
(KV-PG14M40/PG14P42/G/L/N/PG14P70)
C205 1-126-961-11 ELECT 2.2UF 20.00% 50V
C206 1-126-965-91 ELECT 22UF 20.00% 50V
C209 1-126-942-61 ELECT 1000UF 20.00% 25V
C210 1-128-551-11 ELECT 22UF 20.00% 25V
C211 1-126-964-11 ELECT 10UF 20.00% 50V
C212 1-126-942-61 ELECT 1000UF 20.00% 25V
C213 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C214 1-131-664-91 CERAMIC CHIP 0.15UF 10% 10V
C215 1-110-563-11 CERAMIC CHIP 0.068UF 10.00% 16V
C216 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C217 1-164-227-11 CERAMIC CHIP 0.022UF 10.00% 16V
C218 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C219 1-104-509-11 CERAMIC CHIP 0.018UF 10.00% 16V
C220 1-164-227-11 CERAMIC CHIP 0.022UF 10.00% 16V
C221 1-163-018-00 CERAMIC CHIP 0.0056UF 10.00% 50V
C222 1-104-509-11 CERAMIC CHIP 0.018UF 10.00% 16V
C223 1-163-018-00 CERAMIC CHIP 0.0056UF 10.00% 50V
C224 1-126-960-11 ELECT 1UF 20.00% 50V
C225 1-126-960-11 ELECT 1UF 20.00% 50V
C226 1-126-963-11 ELECT 4.7UF 20.00% 50V
C227 1-126-947-11 ELECT 47UF 20.00% 16V
C229 1-126-959-11 ELECT 0.47UF 20.00% 50V
C230 1-135-834-91 CERAMIC CHIP 2.2E+06PF 6.3V
C231 1-135-834-91 CERAMIC CHIP 2.2E+06PF6.3V
C242 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
(KV-PG14M72/L/N)
C242 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
(KV-PG14M40/PG14P42/G/L/N/PG14P70)
C300 1-162-925-11 CERAMIC CHIP 68PF 5.00% 50V
(KV-PG14M72/L/N)
C300 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V
(KV-PG14M40)
C300 1-162-924-11 CERAMIC CHIP 56PF 5.00% 50V
(KV-PG14P42/G/L/N/PG14P70)
C301 1-162-920-11 CERAMIC CHIP 27PF 5.00% 50V
C302 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V
(KV-PG14M40/PG14M72/L/N)
C303 1-162-925-11 CERAMIC CHIP 68PF 5.00% 50V
(KV-PG14M40/PG14M72/L/N)
C304 1-119-662-91 CERAMIC CHIP 150PF 1.00% 50V
C305 1-126-933-11 ELECT 100UF 20.00% 16V
C306 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C307 1-126-957-11 ELECT 0.22UF 20.00% 50V
(EXCEPT KV-PG14M72/L/N)
C308 1-216-295-91 SHORT 0 (KV-PG14M72/L/N)
C308 1-164-392-11 CERAMIC CHIP 390PF 5.00% 50V
(KV-PG14M40/PG14P42/G/L/N)
C309 1-216-295-91 SHORT 0 (KV-PG14M72/L/N)
C309 1-163-263-11 CERAMIC CHIP 330PF 5.00% 50V
(KV-PG14M40)
C310 1-216-295-91 SHORT 0 (KV-PG14M72/L/N)
C310 1-163-131-00 CERAMIC CHIP 390PF 5.00% 50V
(EXCEPT KV-PG14M72/L/N)
C311 1-216-295-91 SHORT 0 (KV-PG14M72/L/N)
C311 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
(KV-PG14M40)
C312 1-162-916-11 CERAMIC CHIP 12PF 5.00% 50V
C315 1-126-961-11 ELECT 2.2UF 20.00% 50V
C316 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V
(KV-PG14M40/PG14M72/L/N)
C317 1-216-295-91 SHORT 0
C318 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14M72/L/N/PG14P70)
C318 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C319 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14M72/L/N/PG14P70)
C319 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C320 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14M72/L/N/PG14P70)
C320 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C321 1-126-963-11 ELECT 4.7UF 20.00% 50V
C323 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C327 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14M72/L/N/PG14P70)
C327 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C328 1-164-222-91 CERAMIC CHIP 0.22UF 25V
(KV-PG14M40/PG14P70/PG14M72/L/N)
C328 1-165-128-11 CERAMIC CHIP 0.22UF 16V
(KV-PG14P42/G/L/N)
C329 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14P70/PG14M72/L/N)
C329 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C330 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14P70/PG14M72/L/N)
C330 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C332 1-126-933-11 ELECT 100UF 20.00% 16V
C335 1-126-947-11 ELECT 47UF 20.00% 16V
C337 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14P70/PG14M72/L/N)
C337 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
A
To Next Page
