Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
8-7
SIIA Chassis
[A]
C1457 1-163-245-11 CERAMIC CHIP 56PF 5% 50V
C1458 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1459 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1460 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1461 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1462 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1463 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1464 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C1465 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C1466 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C1467 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1468 1-101-810-00 CERAMIC 100PF 5% 500V
C1469 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1471 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1475 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1476 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1477 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1478 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1479 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1481 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1483 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1484 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C1485 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C1486 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1487 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1488 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1601 ! 1-801-267-11 VARISTOR TNR10V 431K 660
<CONNECTOR>
CN051 *1-564-508-11 PLUG, CONNECTOR 5P
CN052 *1-770-747-11 CONNECTOR, BOARD TO BOARD 12P
CN201 *1-564-506-11 PLUG, CONNECTOR 3P
CN351 *1-564-509-11 PLUG, CONNECTOR 6P
CN401 *1-564-509-11 PLUG, CONNECTOR 6P
CN402 *1-564-510-11 PLUG, CONNECTOR 7P
(except SSM-14N5A/E/U, 20N5A/E/U)
CN403 *1-564-510-11 PLUG, CONNECTOR 7P
(except PVM-14N5A/E/U, 14N5MDE, 20N5A/E/U)
CN501 *1-580-798-11 CONNECTOR PIN (DY) 6P
CN502 *1-508-768-00 PIN, CONNECTOR (5mm PITCH) 6P
CN601 *1-580-843-11 PIN, CONNECTOR (POWER)
CN602 *1-508-765-00 PIN, CONNECTOR (5mm PITCH) 3P
CN651 1-695-915-11 TAB (CONTACT)
<COMPOSITION CIRCUIT BLOCK>
CP301 1-467-554-21 FILTER BLOCK, COMB
<DIODE>
D001 8-719-914-43 DIODE DAN202K
D002 8-719-914-43 DIODE DAN202K
D003 8-719-914-43 DIODE DAN202K
D004 8-719-914-43 DIODE DAN202K
D005 8-719-914-43 DIODE DAN202K
D101 8-719-914-43 DIODE DAN202K
D102 ! 8-719-983-38 DIODE MTZJ-T-77-36B
D103 8-719-302-43 DIODE EL1Z
D201 8-719-947-26 DIODE MTZJ-T-72-6.2C
D301 8-719-109-85 DIODE RD5.1ESB2
D302 8-719-302-43 DIODE EL1Z
D351 8-719-914-43 DIODE DAN202K
D352 8-719-914-43 DIODE DAN202K
D353 8-719-914-43 DIODE DAN202K
D501 8-719-945-80 DIODE ERC06-15S
D502 8-719-979-85 DIODE EGP20G
D503 8-719-908-03 DIODE GP08D
D504 8-719-908-03 DIODE GP08D
D506 8-719-302-43 DIODE EL1Z
D507 8-719-302-43 DIODE EL1Z
D508 8-719-302-43 DIODE EL1Z
D509 8-719-028-72 DIODE RGP02-17EL-6433
D510 1-249-377-11 CARBON 0.47 5% 1/4W F
D511 8-719-914-43 DIODE DAN202K
D551 8-719-908-03 DIODE GP08D
D552 8-719-109-85 DIODE RD5.1ESB2
D601 ! 8-719-025-88 DIODE GBU4JL-6088
D605 8-719-302-43 DIODE EL1Z
D606 8-719-921-63 DIODE MTZJ-7.5B
D607 8-719-302-43 DIODE EL1Z
D609 8-719-302-43 DIODE EL1Z
D610 8-719-302-43 DIODE EL1Z
D611 8-719-991-33 DIODE 1SS133T-77
D651 8-719-312-10 DIODE RU4AM-T3
D653 8-719-045-48 DIODE FML-G12S
D656 8-719-046-66 DIODE SLR-56MC3F
<FUSE>
F601 ! 1-576-231-11 FUSE (H.B.C.) (4A/250V)
F602 ! 1-576-231-11 FUSE (4A/250V) (PVM-14N5MDE)
F651 ! 1-532-745-11 FUSE, GLASS TUBE (3.15A/125V)
<FERRITE BEAD>
FB001 1-410-397-21 FERRITE 1.1µH
FB601 1-410-396-41 FERRITE 0.45µH
FB602 1-410-396-41 FERRITE 0.45µH
FB603 1-410-396-41 FERRITE 0.45µH
JW390 1-543-840-11 FERRITE 0µH
<IC>
IC001 8-752-895-94 IC CXP85116B-670S
IC002 8-759-527-68 IC M24C01-BN6
IC003 8-759-279-41 IC MM1096BD
IC201 8-759-324-57 IC TDA7052A
IC301 8-752-088-38 IC CXA2060BS
IC401 8-759-000-48 IC MC14052BCP
(except SSM-14N5A/E/U, 20N5A/E/U)
IC402 8-759-984-96 IC BA7604N
(except SSM-14N5A/E/U, 20N5A/E/U)
IC551 8-759-192-71 IC STV9379
IC552 8-759-145-58 IC µPC4558C
IC601 8-749-010-84 IC STR-S6708
IC651 8-749-921-89 IC SE115N
To Next Page
