16 (GB)
Display List
USER CONFIG 1/2, 2/2 menu
·RGB/COMP SEL COMP
·COMP LEVEL SMPTE
·FORMAT DISP AUTO
·LANGUAGE ENGL I SH
·DEGAUSS DELAY 0
USER CONF I G 1 / 2
xM ARKER PHASE 0
·MARKER WI DTH 0
USER CONF I G 2 / 2
REMOTE 1/2 PARALLEL menu, 2/2 SERIAL menu
·1PIN LINE A
·2PIN LINE B
·3PIN TALLY R
·4PIN TALLY G
·6PIN EXT SYNC
·7PIN UNDERSCAN
·8PIN 16:9
REMOTE 1 / 2 PARALLEL
x SINGLE ADDRESS 0
·GROUP ADDRESS 0
·CH(1–4) CONFIG CH1
·INPUT LINE A
·ASPECT 4:3
·SCAN SIZE NORMAL
REMOTE 2 / 2 SER I AL
OPTION CONFIG menu
For details on the OPTION CONFIG menu screens, see page 21 (GB).
KEY PROTECT menu
·KEY PROTECT OFF
KEY PROTECT
(USER CONFIG 1/2 menu) (USER CONFIG 2/2 menu)
(REMOTE 1/2 PARALLEL menu) (REMOTE 2/2 SERIAL menu)
To Next Page
