Connecting an External Microphone
71
To set the microphone to echo
1 From the Start menu, select Control Panel.
2 Double-click YAMAHA DS-XG.
3 Select the Echo tab.
4 You can also customize the setting by choosing options such as Delay Time
and Feedback.
5 Click OK.
To modify the MIDI sound
1 From the Start menu, select Control Panel.
2 Click the YAMAHA DS-XG Audio Config icon. (If you do not see the icon
that you are looking for, click “Display all the options of the Control Panel.”)
3 Select the Synthesizer tab.
4 Select the desired effect, and then click OK.
To adjust the sound volume when recording, double-click in the task tray
located in the lower right corner of the Desktop window.
1 From the Options menu, select Properties.
2 In the Volume Adjust window, select Recording, and then click OK. The
Recording Control window appears.
✍ When recording or using microphone echo, some software options may not be
available.
