18
Connecting the Projector
VIDEO IN
For connecting video equipment with a video output connector.
The audio input connector is available only on VPL-EW275/EW245/EW225/EX275/EX245/
EX225.
INPUT A
For connecting video equipment with a YPBPR output connector.
The audio input connector is available only on VPL-EW275/EW245/EW225/EX275/EX245/
EX225.
Note
Note
Video cable (not supplied)
Audio cable (Phono plug × 2 – stereo mini plug) (not supplied)
Video output
connector
Audio output
connector
Video equipment
Component – Mini D-sub 15-pin cable (not supplied)
Audio cable (Phono plug × 2 – stereo mini plug) (not supplied)
Video equipment
YP
BPR output
connector
Audio output
connector
