21
D-E777/EJ721/EJ725
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
Les composants identifiés par une
marque 0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board.
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3323-640-A MAIN BOARD, COMPLETE
(E777/EJ725: EXCEPT US, FR)
* A-3323-642-A MAIN BOARD, COMPLETE (FR)
* A-3323-644-A MAIN BOARD, COMPLETE (US)
*********************
3-222-736-01 TERMINAL (+), BATTERY
<CAPACITOR>
C101 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C102 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C104 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C110 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
C111 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C112 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C113 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C114 1-113-690-11 ELECT CHIP 220uF 20% 4V
C135 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C154 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C201 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C202 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C204 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C210 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
C211 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C212 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C213 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C214 1-113-690-11 ELECT CHIP 220uF 20% 4V
C235 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C254 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C303 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C304 1-115-156-11 CERAMIC CHIP 1uF 10V
C311 1-110-569-11 TANTAL. CHIP 47uF 20% 4V
C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C313 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C351 1-115-156-11 CERAMIC CHIP 1uF 10V
C352 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C353 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C354 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C356 1-128-705-11 ELECT 100uF 20% 6.3V
C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C402 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C403 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C404 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C405 1-115-156-11 CERAMIC CHIP 1uF 10V
C406 1-119-661-11 TANTAL. CHIP 33uF 20% 6.3V
C407 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C408 1-164-858-11 CERAMIC CHIP 22PF 5% 16V
C409 1-113-689-11 ELECT CHIP 100uF 20% 4V
C410 1-113-689-11 ELECT CHIP 100uF 20% 4V
C411 1-127-772-81 CERAMIC CHIP 33000PF 10% 10V
C412 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C413 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C414 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C415 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C417 1-119-661-11 TANTAL. CHIP 33uF 20% 6.3V
C418 1-128-705-11 ELECT 0PF 0V
C419 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C420 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C421 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C422 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C423 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C424 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C425 1-115-156-11 CERAMIC CHIP 1uF 10V
C426 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C427 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT US)
C428 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C429 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C431 1-125-822-11 TANTALUM 10uF 20% 10V
C432 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C433 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C435 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C436 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C437 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C442 1-115-156-11 CERAMIC CHIP 1uF 10V
C443 1-115-156-11 CERAMIC CHIP 1uF 10V
C444 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C445 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C451 1-115-156-11 CERAMIC CHIP 1uF 10V
C452 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
• Abbreviation
CND : Canadian AUS : Australian
FR : French HK : Hong Kong
G : German JEW : Tourist
CH : Chinese EE : East European
KR : Korean
E13 : AC220-230V area model
E33 : AC100-240V area model
MAIN
