— 10 —
3-6. ORNAMENT, REEL
3-7. HOLDER (FS) ASSY
Claw
1
Ornament, reel
Note : Remove the assembly while removing
the 5 claws and the boss carefully.
Boss
Claw
Claw
Claw
Claw
1
Two screws
(M1.4
×
1.4)
3
Lock Lever (B)
8
Remove soldering from
six head flexible boards.
2
Shaft
6
Shaft
9
Remove the holder (FS) assy
in the direction of the arrow.
7
Bracket (cassette) assy
5
Lock Lever (S)
4
Screw
( M1.4)
