— 8 —
3-2. MAIN BOARD
3-3. BELT (F4)
Claw
6
Screw
(M1.4)
3
Remove soldering (two points)
from plunger solenoid.
1
Remove soldering (six points)
from the head flexible boards.
Head flexible board
2
Remove soldering (four points)
from the leaf switch.
4
Remove soldering
(four points) from motor.
5
Two Screws
(M2.0)
7
MAIN board
Note : Be careful of the claw.
SLIDER
S701
Note: When assembling the MAIN board,
align the slider with the position of S701.
2
Terminal board (Battery
’
3
Belt (F4)
1
Remove soldering from
the battery terminal board.
