Sony WCH20 - Introduction; Function overview; Hardware overview

Introduction
Function overview
Your Wireless Charging Dock is designed for fast, wireless charging of:
• Xperia XZ2
It can be used in portrait or landscape orientation.
Hardware overview
1 Stand slot - landscape orientation
2 Wireless charging area
3 Stand slot - portrait orientation
4 Tab
5 Stand
6 Notification light
• White light: Device is charging
• Red flashes: Charging error
7 Charger/USB Type-C™ cable port
3
