Sony WM-D6C Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
12
WM-D6C/TC-D6C
RV602 1-228-607-00 RES, VAR, CARBON 20K (SPEED TUNE)
RV603 1-241-596-11 RES, ADJ, CERMET 47K
< SWITCH >
S301 1-554-029-11 SWITCH, SLIDE (PLAY/REC)
S302 1-554-222-00 SWITCH, SLIDE (MIC ATT)
S601 1-570-856-11 SWITCH, SLIDE (SPEED TUNE)
< TRANSFORMER >
T301 1-433-244-00 TRANSFORMER, BIAS OSCILLATOR
MAIN
