– 10 –
MOTOR (CAPSTAN/REEL) (M901)
HEAD, MAGNETIC
1
two screws (M1.4)
2
Remove the motor (M901) t
o
direction of the arrow.
1
two pinch levers
3
bracket ass
y
6
head, magnetic
(HP901)
4
flexible board
(CN301)
5
two screws
(M1.4
×
7.2)
2
screw
(M1.4
×
1.6)
