• Waveforms
1 IC701 #• (PHOTO IN)
500 mV/DIV, 50 ms/DIV
2 IC701 !∞ (XTB)
200 mV/DIV, 10 µs/DIV
100 ms
1.4 Vp-p
1 Vp-p
32.768 kHz
3 IC704 !§ (XT)
200 mV/DIV, 10 µs/DIV
4 IC704 @º (VCP)
500 mV/DIV, 500 µs/DIV
0.7 Vp-p
32.768 kHz
1.5 Vp-p
980 µ s
5 Q504 Base
200 mV/DIV, 500 µs/DIV
6 Q504 Collector
200 mV/DIV, 500 µs/DIV
0.6 Vp-p
980
µ s
1.3 Vp-p
980
µ s
7 Q502-1 Collector
200 mV/DIV, 500 µs/DIV
8 IC601 5 (OSC)
10 mV/DIV, 1 ms/DIV
1.3Vp-p
980
µ
s
21 mVp-p
1.6 ms
