– 9 –
CASE (N) ASS’Y
REEL ORNAMENT
3 case (N) ass’y
1 serrat IB locks
1 two serrat IB locks
1 two serrat IB locks
2 two claws
4 Remove the reel ornament to
direction of the arrow
B .
2 Push to the direction of the arrow A ,
remove the claw of knob (OPEN).
1 four claws
3
B
A
