Sony WM-FX473 Service Manual

— 2 —
Sony Corporation
Personal A&V Products Company
98A1668-1
Printed in Japan © 1998.1
Published by Quality Engineering Dept.
(Shibaura)
9-923-306-11
WM-FX473/FX475
WM-FX453/FX455 WM-FX473/FX475
Ref. No. Part No. Description Remarks
Part No. Description Remarks
ELECTRACAL PARTS LIST
ELECTRACAL PARTS LIST
A-3016-916-A MAIN BOARD, COMPLETE (FX453: AEP, IT, E)
*********************
A-3016-918-A MAIN BOARD, COMPLETE (FX453: EE)
*********************
A-3016-920-A MAIN BOARD, COMPLETE (FX455: AEP, E)
*********************
A-3016-921-A MAIN BOARD, COMPLETE (FX455: EE)
*********************
A-3016-972-A MAIN BOARD, COMPLETE (FX455: C&SA)
*********************
A-3016-973-A MAIN BOARD, COMPLETE (FX453: C&SA)
*********************
< FILTER >
CP1 1-236-711-31 FILTER, BAND PASS (EXCEPT EE)
CP1 1-239-813-21 FILTER, BAND PASS (EE)
CP1 ——————————————————
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-858-915-11 MANUAL, INSTRUCTION (AEP, IT, EE)
(ENGLISH, FRENCH, GERMAN, ITALIAN)
3-858-915-21 MANUAL, INSTRUCTION (AEP)
(DUTCH, SWEDISH, SPANISH, PORTUGUESE)
3-858-915-31 MANUAL, INSTRUCTION (AEP)
(POLISH, CZECH, GREEK, TURKISH)
3-858-915-41 MANUAL, INSTRUCTION (AEP, EE)
(RUSSIAN, HUNGARIAN, BULGARIAN)
3-858-915-61 MANUAL, INSTRUCTION (E)
(ENGLISH, SPANISH, CHINESE, KOREAN)
3-858-915-71 MANUAL, INSTRUCTION (9E)
(ENGLISH, SPANISH, CHINESE, KOREAN)
8-953-130-90 HEADPHONE MDR-E801//K SET
A-3016-916-A MAIN BOARD (FX473: AEP, IT, E, 9E)
************
A-3016-918-A MAIN BOARD (FX473: EE)
************
A-3016-920-A MAIN BOARD (FX475: AEP, E, 9E)
************
A-3016-921-A MAIN BOARD (FX475: EE)
************
A-3021-067-A MAIN BOARD (FX475: FR)
************
A-3021-068-A MAIN BOARD (FX473: FR)
************
< FILTER >
1-236-711-31 FILTER, BAND PASS (EXCEPT EE, FR)
1-239-813-21 FILTER, BAND PASS (EE)
1-236-711-21 FILTER, BAND PASS (FR)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
3-861-152-11 MANUAL, INSTRUCTION (AEP, FR, IT, EE)
(ENGLISH, FRENCH, GERMAN, ITALIAN)
3-861-152-21 MANUAL, INSTRUCTION (AEP)
(SPANISH, DUTCH, SWEDISH, PORTUGUESE)
3-861-152-31 MANUAL, INSTRUCTION (AEP)
(POLISH, CZECH, GREEK, TURKISH)
3-861-152-41 MANUAL, INSTRUCTION (AEP, EE)
(RUSSIAN, HUNGARIAN, BULGARIAN, FINNISH)
3-861-152-51 MANUAL, INSTRUCTION (E)
(ENGLISH, CHINESE, KOREAN)
3-861-152-61 MANUAL, INSTRUCTION (9E)
(ENGLISH, CHINESE, KOREAN)
8-953-130-90 HEADPHONE MDR-E801//K SET (FX475: E, 9E)
8-953-224-90 HEADPHONE MDR-E802LP//K SET
(FX475: AEP, FR, EE/FX473)
