Sony WX-C55 - Printed Wiring Board -Control Section

44 44
6-18. PRINTED WIRING BOARD — CONTROL SECTION —
WX-C55
(IC701) C-7
(Q701) C-9
(Q702) C-10
(Q703) D-10
(Q704) C-9
(D701) B-8
(D704) C-10
(D705) C-10
(D706) C-9
D730 F-6
D731 A-7
D732 F-6
D733 B-12
• Semiconductor Location
Ref. No. Location Ref. No. Location
( ) : SIDE B
