Getting to know your phone
Phone overview
4
89
6
7
5
1 2
3
10
12
13
14
15
11
1. Ear speaker
2. Proximity sensor 1
3. Proximity sensor 2
4. Notification LED
5. Volume/Zoom key
6. Touchscreen
7. Menu key
8. Home key
9. Back key
10. Headset connector (CTIA standard)
11. Power key
12. Camera lens
13. Speaker
14. Connector for charger/USB cable
15. Strap hole
