Sony Xperia Z C6603 User Manual

Email
You can handle several email accounts at the same time using the Email application,
including corporate Microsoft Exchange Active Sync accounts. Emails you receive to
your Gmail™ account can be accessed on your device from both the Email and the
Gmail™ applications.
To set up an email account on your device
1
From your Home screen, tap .
2
Find and tap Email.
3
Follow the instructions that appear on the screen to complete the setup.
For some email services, you may need to contact your email service provider for information
on detailed settings for the email account.
Using email
To create and send an email message
1
From your Home screen, tap , then find and tap Email.
2
If you are using several email accounts, tap
at the top of the screen and
select the account you want to send the message from, then tap .
3
Tap To and start typing the recipient's address. Matches are displayed in a
dynamic list. Tap the relevant match or continue typing the complete email
address. To add more recipients, enter a comma ( , ) or a semicolon ( ; ) and
start typing another name. To delete a recipient, tap .
4
To select an email address saved in your contacts, tap , then find and mark
the checkbox next to a recipient field. To add more than one recipient, mark
the checkboxes for the desired recipients. When you are finished, tap Done.
5
Tap Subject and enter the email subject.
6
To attach a file, tap . Select the type of file, then tap the file you want to
attach from the list that appears.
7
In the message area, enter your message text.
8
To set a priority level, press , then tap Set priority and select an option.
9
To add Cc/Bcc fields, press , then tap Show Cc/Bcc.
10
To send the email, tap .
To receive email messages
1
From your Home screen, tap
.
2
Find and tap Email.
3
If you are using several email accounts, tap at the top of the screen and
select the account that you want to check. If you want to check all your email
accounts at once, tap Combined view.
4
To download new messages, tap .
If you have set up a corporate email account, you can set the check frequency to
Automatic
(Push).
To read your email messages
1
From your Home screen, tap .
2
Find and tap Email.
3
If you are using several email accounts, tap at the top of the screen and
select the account you want to check. If you want to check all your email
accounts at once, tap Combined view.
4
In the email inbox, scroll up or down and tap the email you want to read.
54
This is an Internet version of this publication. © Print only for private use.

Sony Xperia Z C6603 Specifications

General

Display	5.0 inches, 1080 x 1920 pixels
RAM	2 GB
Internal Storage	16 GB
Front Camera	2.2 MP
Battery	Non-removable Li-Ion 2330 mAh battery
Operating System	Android 4.1.2 (Jelly Bean), upgradable to 5.1.1 (Lollipop)
Dimensions	139 x 71 x 7.9 mm (5.47 x 2.80 x 0.31 in)
Weight	146 g (5.15 oz)
SIM	Micro-SIM
Water Resistance	IP57 dust and water resistant
Colors	Black, White, Purple
Announced	2013, January
Status	Discontinued
Technology	GSM / HSPA / LTE
2G bands	GSM 850 / 900 / 1800 / 1900
3G bands	HSDPA 850 / 900 / 2100
4G bands	LTE band 1(2100), 3(1800), 5(850), 7(2600), 8(900), 20(800)
Speed	HSPA 42.2/5.76 Mbps, LTE Cat3 100/50 Mbps
GPRS	Yes
EDGE	Yes
Multitouch	Yes, up to 10 fingers
GPU	Adreno 320
Card slot	microSD, up to 64 GB
Video	1080p@30fps, HDR
Alert types	Vibration; MP3, WAV ringtones
Loudspeaker	Yes
3.5mm jack	Yes
WLAN	Wi-Fi 802.11 a/b/g/n, dual-band, Wi-Fi Direct, DLNA, hotspot
Bluetooth	4.0, A2DP
GPS	Yes, with A-GPS, GLONASS
NFC	Yes
Radio	Stereo FM radio, RDS
USB	microUSB 2.0 (MHL TV-out)
Sensors	Accelerometer, gyro, proximity, compass
Messaging	SMS(threaded view), MMS, Email, IM, Push Email
Browser	HTML5
Java	Yes, via Java MIDP emulator
Stand-by	Up to 550 h (2G) / Up to 530 h (3G)
Talk time	Up to 11 h (2G) / Up to 14 h (3G)
Music play	Up to 40 h
Processor	Quad-core 1.5 GHz Krait
Main Camera	13.1 MP
Protection	Shatter proof glass
Pixel density	~441 ppi
