Sony Xperia Z1 Compact D5503 User Manual

10 Main camera lens
11 Camera light
12 Second microphone
13 NFC™ detection area
14 Charger/USB port cover
15 Memory card slot cover
16 Charging dock connector
17 Micro SIM card slot cover
Assembly
A protective plastic sheet is attached to the screen. You should peel off this sheet
before using the touchscreen. Otherwise, the touchscreen might not function
properly.
To insert the micro SIM card
Do not insert a memory card into the micro SIM card slot.
7
This is an Internet version of this publication. © Print only for private use.

Sony Xperia Z1 Compact D5503 Specifications

General

Processor	Qualcomm MSM8974 Snapdragon 800
RAM	2 GB
Internal Storage	16 GB
Front Camera	2 MP
Operating System	Android 4.3 (Jelly Bean), upgradable to 5.1 (Lollipop)
Dimensions	127 x 64.9 x 9.5 mm (5.0 x 2.56 x 0.37 in)
Weight	137 g (4.83 oz)
SIM	Micro-SIM
Network	GSM / HSPA / LTE
GPU	Adreno 330
Card Slot	microSD, up to 64 GB
Main Camera Features	LED flash, HDR, panorama
Video	1080p@30fps
Loudspeaker	Yes
3.5mm Jack	Yes
WLAN	Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA, hotspot
Bluetooth	4.0, A2DP, aptX
GPS	Yes, with A-GPS, GLONASS
NFC	Yes
Sensors	Accelerometer, gyro, proximity, compass
Colors	Black, White, Pink, Lime
Models	D5503
Display	4.3 inches, 720 x 1280 pixels
Rear Camera	20.7 MP
Battery	2300 mAh
IP Certification	IP58
Radio	FM radio
USB	microUSB 2.0 (MHL TV-out)
Talk Time	Up to 18 h (2G)
