Sony Xperia Z1 Test Instructions

Test Instructions (mech)
1277-9815 Rev 3

Sony Mobile Communications AB – Company Internal
7(32)
Pre-Test Preparations
1.4 Software
1.4.1 Software update
1.4.1.1 Software version verification
Check the software version of the phone for fault verification. The latest improvements are found on
the support pages under the support news
http://www.sonyericsson.com/cws/marketingurlportal?pageid=key.SupportZone.Overview
• Start up the phone
• Note: Make sure the phone is in call setup.
• Press the following keypad combination: *#*#7378423#*#*
• Select ‘Service info’
• Select ‘Software info’
• Check the software file revisions and, if needed, update as described below:
For more information, refer to 1220-1333: Generic Repair Manual - mechanical
1.4.1.2 Software version update
Mandatory first repair action!
Use the USB cable to connect with the Micro USB connector of the phone for this purpose!
Ensure the phone is powered off and proceed as follows:
• Open the Emma application and log in.
• Press and hold the volume down key on the phone, connect the phone to the USB cable and then
release the volume down key.
• Select the appropriate service and follow the on-screen instructions.
Note: For phones with eMMC flash memory (built in “SD card” memory), the only service which
erase this eMMC memory is Service’s “Refurbish” and “Customize”. See also emma User Guide
info. http://emma.extranet.sonyericsson.com/documents/emma_user_guide.pdf (see “Service
Types” and “Aspects of large files”)
In Swap flow, when change a phone from Customer A to Customer B, always use the service
Customization script.

Sony Xperia Z1 Specifications

General

RAM	2 GB
Front Camera	2 MP
Battery	Non-removable Li-Ion 3000 mAh
Operating System	Android 4.2 (Jelly Bean), upgradable to 5.1 (Lollipop)
Weight	170 g (6.00 oz)
SIM	Micro-SIM
WLAN	Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA, hotspot
Bluetooth	4.0, A2DP, aptX
GPS	Yes, with A-GPS, GLONASS
NFC	Yes
Sensors	Accelerometer, gyro, proximity, compass, barometer
Display	5.0 inches, 1080 x 1920 pixels
Processor	Qualcomm MSM8974 Snapdragon 800
Storage	16 GB
Main Camera	20.7 MP
Dimensions	144 x 74 x 8.5 mm
Water Resistance	IP58 dust proof and water resistant over 1.5 meter and 30 minutes
Radio	Stereo FM radio with RDS
USB	microUSB 2.0 (MHL TV-out)
