Sony Xperia Z1 Test Instructions

Test Instructions (mech)
1277-9815 Rev 3

Sony Mobile Communications AB – Company Internal
8(32)
2 Tests
2.1 Service Test Mode
Note: Make sure the phone is in call setup when
pressing these touching keypads to get into the Service
menu!
Stamina mode needs to be turned off before entering
Service Test Mode
Settings -> Power management -> STAMINA
Start up the phone and enter the service menus:
• Press the following keypad combination: *#*#7378423#*#*
• Select ‘Service tests’
• Select one of the tests and follow the test instructions as
described below
• To stop the test and return to the ‘Service tests’ menu,
press the Back key
For more information, refer to
1220-1333: Generic Repair Manual - mechanical
The following pictures will show a simplified basic phone for a general visualization of the
service tests!

Sony Xperia Z1 Specifications

General

RAM	2 GB
Front Camera	2 MP
Battery	Non-removable Li-Ion 3000 mAh
Operating System	Android 4.2 (Jelly Bean), upgradable to 5.1 (Lollipop)
Weight	170 g (6.00 oz)
SIM	Micro-SIM
WLAN	Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA, hotspot
Bluetooth	4.0, A2DP, aptX
GPS	Yes, with A-GPS, GLONASS
NFC	Yes
Sensors	Accelerometer, gyro, proximity, compass, barometer
Display	5.0 inches, 1080 x 1920 pixels
Processor	Qualcomm MSM8974 Snapdragon 800
Storage	16 GB
Main Camera	20.7 MP
Dimensions	144 x 74 x 8.5 mm
Water Resistance	IP58 dust proof and water resistant over 1.5 meter and 30 minutes
Radio	Stereo FM radio with RDS
USB	microUSB 2.0 (MHL TV-out)
