– 10 –
SUB PANEL, MECHANISM DECK (MG-25G-136)
MAIN BOARD, HEAT SINK
1
three screws
(PTT2.6
×
8)
1
three screws
(PTT2.6
×
8)
2
sub panel
3
connector
(CN352)
5
screw
(PTT2.6
×
6)
6
mechanism deck
(MG-25G-136)
4
flexible flat cabl
e
(CN351)
5
three screws
(PTT2.6
×
10)
6
two screws
(PTT2.6
×
14)
5
three screws
(PTT2.6
×
10)
1
screw
(PTT2.6
×
8)
7
heat sink
4
main board
3
two ground point
screws
2
rubber cap (25)
1
two screws
(PTT2.6
×
8)
