– 40 –
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
KEY
When indicating parts by reference
number, please include the board.
KEY BOARD
**********
* 3-018-611-01 HOLDER (LCD)
* 3-018-612-01 PLATE, LIGHT GUIDE
* 3-019-149-01 PLATE, LCD
* 3-019-150-01 SHEET (REFLECTOR)
* 3-019-151-01 PLATE (LCD), GROUND
< CAPACITOR >
C901 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C902 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C903 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C904 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN901 1-764-423-11 PIN, CONNECTOR 12P
< DIODE >
D901 8-719-420-90 DIODE MA8051-M
D902 8-719-422-64 DIODE MA8062-M
D903 8-719-422-64 DIODE MA8062-M
D904 8-719-422-64 DIODE MA8062-M
D905 8-719-422-64 DIODE MA8062-M
< IC >
IC901 8-759-365-90 IC LC75824W
< SHORT >
JC901 1-216-295-00 SHORT (CHIP) 0
< LIQUID CRYSTAL DISPLAY >
LCD901 1-801-968-11 DISPLAY PANEL, LIQUID CRYSTAL
< SWITCH >
LSW901 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (OFF)
LSW902 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (SOURCE)
LSW903 1-762-620-11 SWITCH, KEY BOARD (WITH LED)
(MODE/* )
LSW904 1-762-620-11 SWITCH, KEY BOARD (WITH LED)
(+ +), SEEK/AMS)
LSW905 1-762-620-11 SWITCH, KEY BOARD (WITH LED)
(SEEK/AMS, =0 –)
LSW906 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (–)
LSW907 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (SEL)
LSW908 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (+)
LSW909 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (DSPL)
LSW910 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (ATT)
LSW911 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (BTM/SENS)
LSW921 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (6)
LSW922 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (INTRO/1)
LSW923 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (REPEAT/2)
LSW924 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (SHUF/3)
LSW925 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (BL SKIP/6)
LSW926 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (ATA/5)
LSW927 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (MTL/4)
LSW928 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (PTY)
LSW929 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (AF/TA)
LSW930 1-762-620-11 SWITCH, KEY BOARD (WITH LED)
(PRESET +/DISC +)
LSW931 1-762-620-11 SWITCH, KEY BOARD (WITH LED)
(– PRESET/– DISC)
< PILOT LAMP >
PL903 1-517-633-21 LAMP, PILOT (LCD BACK LIGHT)
PL904 1-517-633-21 LAMP, PILOT (LCD BACK LIGHT)
< TRANSISTOR >
Q901 8-729-106-60 TRANSISTOR 2SB1115A
Q902 8-729-106-60 TRANSISTOR 2SB1115A
Q903 8-729-900-53 TRANSISTOR DTC114EK
Q904 8-729-900-53 TRANSISTOR DTC114EK
< RESISTOR >
R901 1-216-045-00 METAL CHIP 680 5% 1/10W
R902 1-216-045-00 METAL CHIP 680 5% 1/10W
R903 1-216-045-00 METAL CHIP 680 5% 1/10W
R904 1-216-049-11 RES, CHIP 1K 5% 1/10W
R905 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R906 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R907 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R908 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R909 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R910 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R921 1-216-045-00 METAL CHIP 680 5% 1/10W
